System And Components
268-4243 BAFFLE GP-RADIATORS/N DLS718-UP
Group No: 268-4243 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2684244 | 1 BAFFLE AS | 1 | |
| 0339412 | RIVET | 13 | |
| 0897960 | WASHER (5.3X25X1.6-MM THK) | 13 | |
| 2684249 | STRIP | 1 | |
| 3512461 | 2 PLATE | 1 | |
| 2684246 | 3 BAFFLE AS | 1 | |
| 0339412 | RIVET | 13 | |
| 0897960 | WASHER (5.3X25X1.6-MM THK) | 13 | |
| 2684251 | STRIP | 1 | |
| 2684247 | 4 BAFFLE AS | 1 | |
| 0339412 | RIVET | 13 | |
| 0897960 | WASHER (5.3X25X1.6-MM THK) | 13 | |
| 2684251 | STRIP | 1 | |
| 2758902 | 5 BAFFLE AS | 1 | |
| 6B4594 | RIVET | 5 | |
| 0339412 | RIVET | 9 | |
| 0897960 | WASHER (5.3X25X1.6-MM THK) | 9 | |
| 8T4121 | 6 WASHER-HARD (11X21X2.5-MM THK) | 27 | |
| 8T4137 | 7 BOLT (M10X1.5X20-MM) | 25 | |
| 3S8664 | 8 CLIP | 2 | |
| 8T4136 | 9 BOLT (M10X1.5X25-MM) | 2 | |
| 2554953 | 10 SEAL (17.4-CM EACH) | ||
| 2554953 | 10A SEAL (176-CM) |
