System And Components
229-2096 LINES GP-SERVICE BRAKES/N DLS1-UP
Group No: 229-2096 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V0852 | 1 CAP-DUST | 1 | |
| 3239342 | 2 HOSE AS | 1 | |
| 3733382 | 3 HOSE AS | 1 | |
| 1645567 | 4 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3112112 | 5 TUBE AS | 1 | |
| 1536241 | 6 ELBOW AS | 2 | |
| 8C8989 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1645624 | 7 ELBOW AS | 2 | |
| 9X2085 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1694273 | 8 TEE AS | 1 | |
| 7X7715 | TEE | 1 | |
| 6V8398 | SEAL-O-RING | 3 | |
| 1942555 | 9 TEE AS | 1 | |
| 1942554 | TEE | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 4D9517 | 10 CLIP | 1 | |
| 5P7464 | 11 CLIP (SLOT) | 2 | |
| 5P7465 | 12 CLIP (TAB) | 2 | |
| 6V1249 | 13 GROMMET (22-MM ID) | 2 | |
| 6V9169 | 14 NUT (13/16-16-THD) | 2 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 16 BOLT (M10X1.5X25-MM) | 2 | |
| 9X8250 | 17 CLIP (LOOP) | 2 | |
| 3620724 | 18 HOSE AS | 1 |
