System And Components
298-4714 CONVERSION GP-GASFOR USE WITH CONVERSION TO AIR FUEL RATIO CONTROL
Group No: 298-4714
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W8129 | 1 SUPPORT | 2 | |
| 6I0236 | 2 VALVE GP-FUEL RATIO | 1 | |
| 6I0327 | 3 ADAPTER | 1 | |
| 6L2849 | 4 JOINT AS-TUBE | 2 | |
| 9X7521 | SEAL | 2 | |
| 6S7721 | 5 LEVER | 1 | |
| 6V9163 | 6 ROD END (BEARING) | 1 | |
| 7E9748 | 7 ROD END (BEARING) | 1 | |
| 0910081 | 8 SPACER (10.5X20X10-MM THK) | 8 | |
| 1076314 | 9 TUBE AS | 1 | |
| 1076315 | 10 TUBE AS | 1 | |
| 1149269 | 11 SLEEVE | 2 | |
| 1195092 | 12 ROD | 1 | |
| 1640433 | 13 PLATE | 1 | |
| 3305584 | 14 ACTUATOR | 1 | |
| 2635007 | 15 LEVER-THROTTLE | 1 | |
| 2700378 | 16 BRACKET | 1 | |
| 0S1571 | 17 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1587 | 18 BOLT (1/2-13X1.75-IN) | 4 | |
| 0S1591 | 19 BOLT (3/8-16X1.5-IN) | 4 | |
| 0S1619 | 20 BOLT (3/8-16X3-IN) | 2 | |
| 0T0055 | 21 BOLT (3/8-16X4.25-IN) | 2 | |
| 1B7182 | 22 BOLT (5/16-18X1.25-IN) | 3 | |
| 1P4579 | 23 FLANGE-HALF | 2 | |
| 3B1915 | 24 BOLT (3/8-16X1.375-IN) | 4 | |
| 3J7354 | 25 SEAL-O-RING | 1 | |
| 3K0360 | 26 SEAL-O-RING | 1 | |
| 4F2294 | 27 NUT-JAM (5/16-24-THD) | 1 | |
| 4J0524 | 28 SEAL-O-RING | 1 | |
| 5M2894 | 29 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 5P8245 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5S0003 | 31 NUT (5/16-18-THD) | 2 | |
| 6V2317 | 32 BOLT (M8X1.25X30-MM) | 4 | |
| 8L4496 | 33 NUT-JAM (5/16-24 LH-THD) | 1 | |
| 9M1974 | 34 WASHER-HARD (8.8X16X2-MM THK) | 9 | |
| 9S4182 | 35 PLUG (7/16-20-THD) | 1 | |
| 9S4185 | 36 PLUG (3/4-16-THD) | 1 | |
| 9S8752 | 37 NUT-FULL (3/8-16-THD) | 5 |
