System And Components
222-5947 COVER GP-CYLINDER BLOCKS/N KHX5707-UP
Group No: 222-5947 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W6544 | 1 COVER | 1 | |
| 4P5918 | 2 CLIP | 3 | |
| 4Y9652 | 3 GASKET | 3 | |
| 7W3872 | 4 SLEEVE | 6 | |
| 9X2099 | 5 STUD (M8X1.25X52.75-MM) | 1 | |
| 1107618 | 6 BOLT AS | 3 | |
| 6V5215 | BOLT (M8X1.25X16-MM) | 1 | |
| 9M1974 | WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 2225893 | 7 COVER AS | 1 | |
| 6V5698 | SCREW-BUTTON HEAD (M4X0.7X10-MM) | 2 | |
| 3424977 | 8 COVER-SIDE | 2 | |
| 2103321 | 9 STUD (M8X1.25-THD) | 1 | |
| 5C7261 | 10 NUT (M8X1.25-THD) | 1 | |
| 6V2317 | 11 BOLT (M8X1.25X30-MM) | 23 | |
| 8T4224 | 12 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9M1974 | 13 WASHER-HARD (8.8X16X2-MM THK) | 22 | |
| 5170553 | 14 GASKET | 1 |
