System And Components
187-6279 LINES GP-TURBOCHARGER OILS/N KHX543-UP
Group No: 187-6279 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1833399 | 1 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2466036 | 2 HOSE | 1 | |
| 1876294 | 3 HOSE AS-OIL SUPPLY | 1 | |
| 2501424 | 4 ELBOW AS | 1 | |
| 6V8724 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 1978419 | 5 GASKET | 1 | |
| 2109246 | 6 SEAL-O-RING | 1 | |
| 9X2099 | 7 STUD (M8X1.25X52.75-MM) | 2 | |
| 8T4224 | 8 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 6V5218 | 9 BOLT (M8X1.25X35-MM) | 2 | |
| 2608630 | 10 TUBE AS-DRAIN | 1 | |
| 2608631 | 11 TUBE AS-DRAIN | 1 | |
| 2843502 | 12 CLAMP-BAND | 2 | |
| 2Y5829 | 13 NUT (M10X1.5-THD) | 1 | |
| 6V4248 | 14 BOLT (M10X1.5X25-MM) | 1 | |
| 6V5839 | 15 WASHER (11X21X2.5-MM THK) | 2 | |
| 7S0530 | 16 CLIP | 1 | |
| 9M9840 | 17 CLIP | 1 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 2 |
