System And Components
206-4228 LINES GP-WATER -ENGINES/N KHX1-522
Group No: 206-4228 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2275942 | 1 HOUSING-WATER REGULATOR | 1 | |
| 1265466 | 2 GASKET | 1 | |
| 1154223 | 3 REGULATOR-WATER TEMPERATURE (97-DEG C)(COOLANT) | 2 | |
| 2225915 | 4 GASKET-WATER REGULATOR (TEMPERATURE REGULATOR HOUSING) | 1 | |
| 1605131 | 5 PIPE (OUTLET) | 1 | |
| 7E0759 | 6 HOSE | 1 | |
| 3510274 | 7 ADAPTER AS | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 5P9617 | ADAPTER | 1 | |
| 3779603 | 8 VALVE AS-FLUID SAMPLING (ENGINE COOLANT) | 1 | |
| 6V9027 | SEAL-O-RING | 1 | |
| 1549023 | VALVE-SAMPLING | 1 | |
| 9M1974 | 9 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 6V3940 | 10 BOLT (M8X1.25X25-MM) | 6 | |
| 5P8347 | 11 BOLT (M8X1.25X70-MM) | 2 | |
| 6V5223 | 12 BOLT (M8X1.25X100-MM) | 1 | |
| 3960405 | 13 PLUG AS | 4 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 1570670 | 14 CAP-DUST | 1 | |
| 3985598 | 15 PLUG AS | 1 | |
| 6V9027 | SEAL-O-RING | 1 | |
| 3603677 | PLUG (7/16-20-THD) | 1 | |
| 3473148 | 16 CLAMP-BAND | 2 |
