System And Components
238-4802 LINES GP-WATER -ENGINES/N KHX523-UP
Group No: 238-4802 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7E0759 | 1 HOSE | 1 | |
| 3473148 | 3 CLAMP-BAND | 2 | |
| 1193075 | 4 REGULATOR-WATER TEMPERATURE (94-DEG C)(COOLANT) | 2 | |
| 1265466 | 5 GASKET | 1 | |
| 2225915 | 6 GASKET-WATER REGULATOR (TEMPERATURE REGULATOR HOUSING) | 1 | |
| 1605131 | 7 PIPE (OUTLET) | 1 | |
| 2275942 | 8 HOUSING-WATER REGULATOR | 1 | |
| 3960405 | 10 PLUG AS | 4 | |
| 6V6609 | 10A SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 3985598 | 11 PLUG AS | 1 | |
| 6V9027 | 11A SEAL-O-RING | 1 | |
| 3603677 | PLUG (7/16-20-THD) | 1 | |
| 3960403 | 12 PLUG AS | 1 | |
| 6V3250 | 12A SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 5P8347 | 13 BOLT (M8X1.25X70-MM) | 2 | |
| 6V3940 | 14 BOLT (M8X1.25X25-MM) | 6 | |
| 6V5223 | 15 BOLT (M8X1.25X100-MM) | 1 | |
| 9M1974 | 16 WASHER-HARD (8.8X16X2-MM THK) | 6 |
