251-1325 RADIATOR & MOUNTING GPS/N 5351-UP
Group No: 251-1325 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1616963 | 1 CLAMP | 2 | |
| 5D1026 | 2 CLAMP-BAND | 1 | |
| 8F8151 | 3 VALVE-SHUTOFF (RADIATOR DRAIN) | 1 | |
| 1099436 | 4 TANK AS-COOLANT (INCLUDES COOLANT LEVEL SWITCH) | 1 | |
| 1713370 | CAP AS (COOLANT OVERFLOW) | 1 | |
| 2040920 | CAP AS (COOLANT FILL) | 1 | |
| 2546043 | 5 HOSE | 1 | |
| 2546044 | 6 HOSE | 1 | |
| 2547027 | 7 RADIATOR & AFTERCOOLER GP (WITH TRANSMISSION OIL COOLER) | 1 | |
| 2550872 | 8 BRACKET | 1 | |
| 2094573 | 9 CLAMP-T BOLT | 2 | |
| 2176885 | 10 CLAMP | 2 | |
| 3P9847 | 11 CLIP | 1 | |
| 5P9299 | 13 CLIP (LOOP) | 3 | |
| 6V5386 | 14 CLIP | 1 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4133 | 16 NUT (M10X1.5-THD) | 1 | |
| 8T4137 | 17 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4139 | 18 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4192 | 19 BOLT (M12X1.75X25-MM) | 2 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 9D3768 | 21 GROMMET | 1 | |
| 5P0767 | 22 HOSE (60-CM) | ||
| 8C3681 | 23 HOSE-DRAIN (88.8-CM) | ||
| 8C3681 | 23A HOSE-DRAIN (95.2-CM) | ||
| 5P9909 | 24 SEAL (0.8-M EACH) | ||
| 5P9909 | 24A SEAL (1-M EACH) |
