System And Components
251-1322 LINES GP-FUELS/N 535259-UP
Group No: 251-1322 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P4278 | 1 CLAMP-HOSE | 1 | |
| 1901105 | 2 PUMP GP-FILTER & FUEL TRANSFER | 1 | |
| 2594783 | 3 HOSE AS | 1 | |
| 3455457 | 4 HOSE AS | 1 | |
| 2632602 | 5 HOSE AS | 1 | |
| 1488340 | 6 CONNECTOR AS | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488345 | 7 CONNECTOR AS | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488365 | 8 ELBOW AS | 1 | |
| 8T6876 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488370 | 9 ELBOW AS | 1 | |
| 6V9851 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488372 | 10 ELBOW AS | 1 | |
| 6V8721 | ELBOW | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488378 | 11 ELBOW AS | 2 | |
| 6V8724 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6D4247 | 13 CLIP | 4 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4137 | 16 BOLT (M10X1.5X20-MM) | 4 | |
| 8C6959 | 17 HOSE (62-CM) | ||
| 1211340 | 18 ANGLE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8T4136 | 19 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 2006345 | 21 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 7K1181 | 22 STRAP-CABLE | 2 | |
| 1S0994 | 23 CLIP (LOOP) | 3 |
