System And Components
384-0607 PUMP GP-UNIT INJECTOR HYDS/N KHX43503-UP
Group No: 384-0607 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1537036 | 1 SPOOL | 1 | |
| 3134620 | 2 SCREW-PAN HEAD (M5X0.8X25-MM) | 3 | |
| 1798128 | 3 SEAL-O-RING (FUEL SYSTEM) | 1 | |
| 2188655 | 4 BOLT-SOCKET HEAD (M5X0.8X42-MM) | 8 | |
| 2285897 | 5 BOLT-TORX (M8X1.25X136.7-MM) | 4 | |
| 2392402 | 6 SEAL-O-RING | 4 | |
| 3188144 | 7 CONNECTOR AS | 1 | |
| 5P8106 | WIRE-ELECTRICAL (26-CM) | ||
| 1797400 | SEAL | 2 | |
| 2605716 | 8 SPOOL | 1 | |
| 3908589 | 9 COVER AS-PUMP | 1 | |
| 7S5005 | DOWEL | 1 | |
| 8C6711 | 10 NUT-RETAINER (1/2-20-THD) | 1 | |
| 2620284 | 11 RING-RETAINING | 1 | |
| 5C2890 | 12 NUT (M6X1-THD) | 1 | |
| 9X8267 | 13 WASHER (6.6X12X2-MM THK) | 1 | |
| 1N8062 | 14 BEARING AS-NEEDLE | 1 | |
| 3963298 | KIT-FUEL PUMP (FUEL TRANSFER PUMP COVER) | 1 |
