System And Components
476-8768 PUMP GP-UNIT INJECTOR HYDS/N KHX43503-UP
Group No: 476-8768 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N8062 | 1 BEARING AS-NEEDLE | 1 | |
| 5C2890 | 2 NUT (M6X1-THD) | 1 | |
| 6V5048 | 3 SEAL-O-RING | 3 | |
| 8C6711 | 4 NUT-RETAINER (1/2-20-THD) | 1 | |
| 9X8267 | 5 WASHER (6.6X12X2-MM THK) | 1 | |
| 1537036 | 6 SPOOL | 1 | |
| 1798128 | 7 SEAL-O-RING | 1 | |
| 1931736 | 8 SEAL-O-RING | 1 | |
| 2188655 | 9 BOLT-SOCKET HEAD (M5X0.8X42-MM) | 8 | |
| 2285897 | 10 BOLT-TORX (M8X1.25X136.7-MM) | 4 | |
| 2392402 | 11 SEAL-O-RING | 4 | |
| 2605716 | 12 SPOOL | 1 | |
| 2620284 | 13 RING-RETAINING | 1 | |
| 3134620 | 14 SCREW-PAN HEAD (M5X0.8X25-MM) | 3 | |
| 3908589 | 15 COVER AS-PUMP | 1 | |
| 7S5005 | DOWEL | 1 | |
| 2275904 | SEAL-O-RING | 1 | |
| 3963298 | KIT-FUEL PUMP (FUEL TRANSFER PUMP COVER) | 1 |
