255-8094 BATTERY & WIRING GPS/N 535232-499

Group No: 255-8094 · Commonality

Part Number	Part Name	Qty
3E8320	1 PLATE-INSTRUCTION (BATTERY)	1
6T1847	2 ROD-RETAINING	3
7N0718	3 SWITCH GP-DISCONNECT (BATTERY)	1
9W0742	4 BLOCK GP-JUNCTION (BATTERY)	1
1240378	5 CABLE AS	1
1M6119	BOLT (5/16-18X1.375-IN)	2
1M6120	NUT (5/16-18-THD)	2
5P0761	CABLE (00-GA, RED)(12-CM)
9G0003	COVER AS-TERMINAL (BLACK)	1
9G0004	COVER AS-TERMINAL (RED)	1
1738458	6 ANGLE AS	1
2042281	7 STRAP-CABLE	2
2558090	8 CABLE AS	1
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	2
5P0761	CABLE (00-GA, RED)(158-CM)
8N0869	COVER-TERMINAL (RED)(134-CM)	2
2558091	9 CABLE AS	1
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	1
5P0761	CABLE (00-GA, RED)(68-CM)
8N0869	COVER-TERMINAL (RED)	1
9G0002	COVER AS-TERMINAL (RED)	1
2558092	10 CABLE AS	1
1S7252	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
5P0747	CABLE (00-GA, BLACK)(106-CM)
9G0005	COVER AS-TERMINAL (BLACK)	1
9G8909	COVER-TERMINAL (BLACK)	1
2558100	11 CABLE AS	1
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	2
5P0747	CABLE (00-GA, BLACK)(75-CM)
9G8909	COVER-TERMINAL (BLACK)	2
2704428	12 BRACKET AS	1
2748380	13 BRACKET AS	1
2905562	14 MOUNT (DUAL SWIVEL)	1
3400745	15 PLATE AS (RH)	1
3400747	16 PLATE AS (LH)	1
1152422	17 BATTERY GP (12-VOLT, MAINTENANCE FREE, WET)	2
1231373	CAP AS-FILLER (7/8-9-THD)	6
6V8189	18 NUT (5/16-18-THD)	3
8T4121	19 WASHER-HARD (11X21X2.5-MM THK)	18
8T4137	20 BOLT (M10X1.5X20-MM)	16
8T4195	21 BOLT (M10X1.5X30-MM)	2
8T4223	22 WASHER-HARD (13.5X25.5X3-MM THK)	1
8T4224	23 WASHER-HARD (8.8X16X2-MM THK)	3
8T4244	24 NUT (M12X1.75-THD)	1
9M8406	25 CLIP (LOOP)	11
