System And Components
258-6842 BATTERY & WIRING GPS/N 535274-606
Group No: 258-6842 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E8320 | 1 PLATE-INSTRUCTION (BATTERY) | 1 | |
| 6T1847 | 2 ROD-RETAINING | 3 | |
| 7N0718 | 3 SWITCH GP-DISCONNECT (BATTERY) | 1 | |
| 9W0742 | 4 BLOCK GP-JUNCTION (BATTERY) | 1 | |
| 1240378 | 5 CABLE AS | 1 | |
| 8C5917 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 8T9757 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 2 | |
| 1M6120 | NUT (5/16-18-THD) | 2 | |
| 1598049 | CABLE (00-GA, RED)(12-CM) | ||
| 9G0003 | COVER AS-TERMINAL (BLACK) | 1 | |
| 9G0004 | COVER AS-TERMINAL (RED) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 2042281 | 6 STRAP-CABLE | 2 | |
| 2558092 | 7 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 8C5918 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 9G0005 | COVER AS-TERMINAL (BLACK) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 9G8909 | COVER-TERMINAL (BLACK) | 1 | |
| 1598050 | CABLE (00-GA, BLACK)(106-CM) | ||
| 1148843 | SLEEVE-PLASTIC (5-CM) | ||
| 2567573 | 8 ANGLE | 1 | |
| 2591948 | 9 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 1598049 | CABLE (00-GA, RED)(82-CM) | ||
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 9G0002 | COVER AS-TERMINAL (RED) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 8T9756 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 2704426 | 10 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 1598050 | CABLE (00-GA, BLACK)(75-CM) | ||
| 9G8909 | COVER-TERMINAL (BLACK) | 2 | |
| 2704428 | 11 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2735791 | 12 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 1598049 | CABLE (00-GA, RED)(140-CM) | ||
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 2748380 | 13 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2905562 | 14 MOUNT (DUAL SWIVEL) | 1 | |
| 3356635 | 15 PLATE AS (RH) | 1 | |
| 3357116 | 16 PLATE AS (LH) | 1 | |
| 1152422 | 17 BATTERY GP (12-VOLT, MAINTENANCE FREE, WET) | 2 | |
| 1231373 | CAP AS-FILLER (7/8-9-THD) | 6 | |
| 6V8189 | 18 NUT (5/16-18-THD) | 3 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 13 | |
| 8T4137 | 20 BOLT (M10X1.5X20-MM) | 9 | |
| 8T4189 | 21 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4191 | 22 BOLT (M10X1.5X16-MM) | 2 | |
| 8T4136 | 23 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4223 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4224 | 25 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 8T4244 | 26 NUT (M12X1.75-THD) | 1 | |
| 9M8406 | 27 CLIP (LOOP) | 11 |
