282-4220 PANEL GP-CIRCUIT BREAKERS/N 535291-UP

Group No: 282-4220 · Commonality

Part Number	Part Name	Qty
6T3644	1 CIRCUIT BREAKER AS (20-AMPERE)(MACHINE CONTROL)	1
6V8376	SCREW-MACHINE (8-32X0.25-IN)	2
9B7233	LOCKWASHER	2
1251302	2 SWITCH GP-MAGNETIC (24-VOLT)(START RELAY)	1
1712210	3 CIRCUIT BREAKER AS (80-AMPERE)(AIR INLET HEATER)	1
2532111	LOCKWASHER	2
6V8187	NUT (1/4-28-THD)	2
8T4205	WASHER-HARD (7.2X14.5X2-MM THK)	2
1712212	4 CIRCUIT BREAKER AS (105-AMPERE)(ALTERNATOR)	1
2532111	LOCKWASHER	2
6V8187	NUT (1/4-28-THD)	2
8T4205	WASHER-HARD (7.2X14.5X2-MM THK)	2
1712212	4A CIRCUIT BREAKER AS (105-AMPERE)(MAIN)	1
2532111	LOCKWASHER	2
6V8187	NUT (1/4-28-THD)	2
8T4205	WASHER-HARD (7.2X14.5X2-MM THK)	2
2575124	6 WIRE AS	1
2577147	7 WIRE AS	1
3000500	8 PLATE AS	1
8T3612	NUT-WELD (M8X1.25-THD)	1
2731743	9 PANEL AS	1
2731750	10 STRAP	1
2769535	11 FILM-IDENTIFICATION (CIRCUIT PANEL)	1
0301193	12 SCREW-MACHINE (10-32X19.05-MM)	6
4B4863	13 WASHER (4.7X11X1.2-MM THK)	2
5C9553	14 BOLT (M6X1X16-MM)	2
5P8394	15 SCREW-MACHINE (8-32X0.75-IN)	2
7K1181	16 STRAP-CABLE	2
8T0328	17 WASHER-HARD (5.5X10X1-MM THK)	6
8T4200	18 BOLT (M8X1.25X16-MM)	4
8T4224	19 WASHER-HARD (8.8X16X2-MM THK)	5
9X8256	20 WASHER (6.6X12X2-MM THK)	2
3021525	21 HARNESS AS-CHASSIS	1
7X0818	22 BOLT (M8X1.25X45-MM)	1
0961357	23 CLIP	1
1336934	24 SPACER (11X20X25-MM THK)	1
