352-1203 WIRING GP-MACHINES/N 535500-578

Group No: 352-1203 · Commonality

Part Number	Part Name	Qty
3E5169	1 GUARD-SWITCH	1
4H1225	2 WASHER (11X22X6-MM THK)	2
4P7751	3 WIRE AS	1
1243019	4 BRACKET AS	2
8T3490	NUT-WELD (M10X1.5-THD)	1
1279323	5 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
1310359	6 PLATE-IDENTIFICATION (ENGINE STOP, RUN)	1
1400860	7 STRAP AS-GROUND	1
1457028	8 SENSOR GP-TEMPERATURE (TORQUE CONVERTER OIL)	1
1586634	9 SWITCH GP-TOGGLE (GROUND LEVEL SHUTDOWN)	1
1631201	10 HORN AS (24-VOLT, LOW TONE)	1
1658764	11 BRACKET AS	1
8T3597	NUT-WELD (M12X1.75-THD)	1
2139100	12 ALARM AS (BACKUP)(BACKUP)	1
1028802	KIT-RECEPTACLE (2-PIN)	1
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	2
9X1813	SLEEVE (29-CM)
2566007	13 HARNESS AS-HYDRAULIC TANK	1
1028801	KIT-RECEPTACLE (12-PIN)	1
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	9
8T8730	SOCKET-CONNECTOR (16-GA TO 20-GA)	11
8T8737	PLUG-SEAL	4
1148843	SLEEVE-PLASTIC (100-CM)
1148844	SLEEVE-PLASTIC (20-CM)
1257874	TUBE-HEAT SHRINK (5.72-MM DIA)(10-CM)
1552260	KIT-CONNECTING PLUG (3-PIN)	2
1552270	KIT-CONNECTING PLUG (2-PIN)	3
2602019	14 HARNESS AS-WORK TOOL (GRAPPLE, WINCH)	1
9X3401	PIN-CONNECTOR (16-GA TO 18-GA)	20
1261767	PIN-CONNECTOR (14-GA TO 16-GA)	22
3E3389	WEDGE-RECEPTACLE LOCK (8-PIN)	1
8T8737	PLUG-SEAL	20
1261767	PIN-CONNECTOR (14-GA TO 16-GA)	2
9X3402	SOCKET-CONNECTOR (16-GA TO 18-GA)	18
1261768	SOCKET-CONNECTOR (14-GA TO 16-GA)	20
1552274	KIT-CONNECTING PLUG (6-PIN)	1
1552260	KIT-CONNECTING PLUG (3-PIN)	1
1552270	KIT-CONNECTING PLUG (2-PIN)	7
1028802	KIT-RECEPTACLE (2-PIN)	5
1028803	KIT-RECEPTACLE (3-PIN)	1
1028805	KIT-RECEPTACLE (6-PIN)	1
1028806	KIT-RECEPTACLE (8-PIN)	1
1028801	KIT-RECEPTACLE (12-PIN)	1
5P0765	HOSE (217-CM)
1257875	TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM)
2644297	15 SENSOR AS-TEMPERATURE (2-PIN)(HYDRAULIC OIL)	1
1376645	PAD-CONNECTOR	1
3021526	16 HARNESS AS-ENGINE	1
1028802	KIT-RECEPTACLE (2-PIN)	4
3S2093	STRAP-CABLE	1
3T4688	TERMINAL-RING (4-GA, 7/16-IN SCREW)	1
5P4571	TERMINAL-BLADE (14-GA TO 16-GA)	4
7G7917	PLUG-SEAL	1
7G7919	PLUG-SEAL	1
8N1517	RECEPTACLE AS-CONNECTOR (25-PIN)	1
8N1522	NUT (2-1/4-16-THD)	1
8N1521	BELL AS-END	1
8N1523	LOCKWASHER	1
9X6856	PIN-CONNECTOR (16-GA TO 18-GA)	15
8N1540	PIN-CONNECTOR (12-GA TO 14-GA)	4
8N1542	PIN-CONNECTOR (10-GA)	1
8N1544	PIN-CONNECTOR (8-GA)	1
8N1546	PIN-CONNECTOR (6-GA)	1
8N1548	PIN-CONNECTOR (4-GA)	1
8T8730	SOCKET-CONNECTOR (16-GA TO 20-GA)	20
8T8737	PLUG-SEAL	61
9W0844	SOCKET-CONNECTOR (14-GA TO 16-GA)	8
9X6772	STRAP-CABLE	3
1123587	BOOT (40-PIN)	1
1148845	SLEEVE-PLASTIC (20-CM)
1193662	TUBE-HEAT SHRINK (10.85-MM DIA)(26-CM)
1257874	TUBE-HEAT SHRINK (5.72-MM DIA)(15-CM)
1261774	COVER-CONNECTOR	1
2L8049	TERMINAL-RING (6-GA, NO. 10 SCREW)	1
2L8057	TERMINAL-RING (8-GA, NO. 10 SCREW)	1
2L8051	TERMINAL-RING (6-GA, 5/16-IN SCREW)	1
5P3455	TERMINAL-RING (8-GA, 5/16-IN SCREW)	1
1342540	RECEPTACLE AS-CONNECTOR (3-PIN)	1
1352543	BOOT (RED)	2
1552260	KIT-CONNECTING PLUG (3-PIN)	1
1552270	KIT-CONNECTING PLUG (2-PIN)	4
1607689	PLUG AS-CONNECTOR (70-PIN)	1
1599322	SEAL-O-RING	1
2042281	STRAP-CABLE	1
3521202	17 PANEL GP-CIRCUIT BREAKER	1
0338248	18 CLIP (LOOP)	1
1305300	19 CLIP	2
1325789	20 CLIP (LADDER)	3
1470385	21 CLIP	1
1644227	22 CLIP	1
3107300	23 CLIP (LOOP)	1
4P7428	24 CLIP (LADDER)	1
4P7581	25 CLIP (LADDER)	13
4S1936	26 CLIP	1
4S1962	27 CLIP (LOOP)	1
4S5719	28 SPACER (10.31X25X12.7-MM THK)	2
5C7261	29 NUT (M8X1.25-THD)	1
6D4244	30 CLIP (LOOP)	2
6D4246	31 CLIP (LOOP)	1
7J0204	32 SEAL-O-RING	1
7K1181	33 STRAP-CABLE	66
7X2621	34 BOLT (M10X1.5X12-MM)	2
8L2786	35 SEAL-O-RING	1
8M2769	36 CLIP	2
8M2773	37 CLIP (LOOP)	4
8T4121	38 WASHER-HARD (11X21X2.5-MM THK)	22
8T4133	39 NUT (M10X1.5-THD)	3
8T4136	40 BOLT (M10X1.5X25-MM)	2
8T4137	41 BOLT (M10X1.5X20-MM)	14
8T4139	42 BOLT (M12X1.75X30-MM)	1
8T4195	43 BOLT (M10X1.5X30-MM)	1
8T4223	44 WASHER-HARD (13.5X25.5X3-MM THK)	2
8T4224	45 WASHER-HARD (8.8X16X2-MM THK)	4
8T4244	46 NUT (M12X1.75-THD)	1
8T4908	47 BOLT (M8X1.25X25-MM)	3
