System And Components
139-4126 BRAKE & PLANETARY GPS/N 5351-6868
Group No: 139-4126 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T2925 | 1 PIN-SPRING | 3 | |
| 1381645 | 2 PIN-SPRING | 3 | |
| 1437155 | 3 PISTON | 1 | |
| 1437156 | 4 PLATE-REACTION | 1 | |
| 1437157 | 5 CARRIER-PLANETARY | 1 | |
| 1437345 | 6 SEAL | 1 | |
| 1437352 | 7 SEAL | 1 | |
| 4442262 | 8 WASHER-THRUST | 6 | |
| 1437509 | 9 SHAFT-PLANETARY | 3 | |
| 1437510 | 10 BUSHING | 3 | |
| 4690883 | 11 DOWEL | 4 | |
| 1394130 | 12 GEAR-SUN (15-TEETH) | 1 | |
| 3846493 | 13 GEAR-RING (66-TEETH) | 1 | |
| 1437154 | 14 GEAR-PLANETARY (24-TEETH) | 3 | |
| 3341030 | 15 DISC-FRICTION | 1 | |
| 3P7832 | 16 DOWEL | 4 | |
| 9C9844 | 17 SPRING | 4 |
