Assembly
100%

251-9734 FRAME AS-FRONTS/N 5351-258

Group No: 251-9734 · Commonality
Part NumberPart NameQty
3W91171 BAR1
8X47182 ANGLE AS1
8T3490NUT-WELD (M10X1.5-THD)1
17121703 PLATE AS2
9X6269NUT-WELD (M16X2-THD)1
23032464 BRACKET AS2
8T3597NUT-WELD (M12X1.75-THD)1
23032505 PLATE AS8
8T3597NUT-WELD (M12X1.75-THD)1
9R26406 BOSS (M12X1.75X25-MM)2
27551497 PLATE AS1
8T3490NUT-WELD (M10X1.5-THD)2
11020238 STUD-WELD (M10X1.5X25-MM)1
11290739 STUD-WELD (M12X1.75X21.1-MM)12
7T109910 LINK30
8R778311 BOSS (M12X1.75X45-MM)2
8T363512 STUD-WELD (M12X1.75X34.93-MM)5
8T385113 BOSS-WELD (M10X1.5X17.5-MM)21
8T493514 BOSS-WELD (M10X1.5X45-MM)4
8T496715 STUD-WELD (M10X1.5X23-MM)2
9C493516 PLATE1
9C680917 BLOCK (M10X1.5-MM)4
8T646218 BOSS-WELD (M10X1.5X25-MM)2
253080319 FRAME AS1
222448319A TRUNNION2
264780019B BUSHING4
