System And Components
246-5998 GUARD GP-BOTTOM -FRONT FRAMES/N 5351-499
Group No: 246-5998 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1701259 | 1 PLATE | 1 | |
| 1703503 | 2 GUARD AS-ENGINE | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1701259 | PLATE | 1 | |
| 2228632 | 3 PLATE AS | 1 | |
| 2228635 | 4 PLATE AS | 1 | |
| 2228636 | 5 PLATE AS | 1 | |
| 2233645 | 6 PLATE | 1 | |
| 2295424 | 7 PLATE | 2 | |
| 2519735 | 8 PLATE AS | 1 | |
| 2546827 | 9 PLATE AS | 1 | |
| 1488562 | BOSS (M10X1.5X50-MM) | 4 | |
| 7X0515 | 10 WASHER-HARD (17X35X5-MM THK) | 17 | |
| 7X0583 | 11 WASHER-HARD (17X45X6-MM THK) | 8 | |
| 7X2553 | 12 BOLT (M16X2X40-MM) | 17 | |
| 7X2563 | 13 BOLT (M20X2.5X60-MM) | 9 | |
| 8T4779 | 14 BOLT (M16X2X35-MM) | 8 | |
| 8T5439 | 15 WASHER-HARD (21.5X45X6-MM THK) | 9 |
