Assembly
100%

259-2633 GUARD GP-LINES -REAR FRAME, GRAPPLES/N 5351-UP

Group No: 259-2633 · Commonality
Part NumberPart NameQty
17793811 PLATE1
20078712 PLATE1
20078723 PLATE1
20084574 PLATE AS1
8T3490NUT-WELD (M10X1.5-THD)1
20084585 PLATE AS1
8T3490NUT-WELD (M10X1.5-THD)1
27730336 PLATE AS1
27730357 PLATE AS1
27797308 GUARD AS1
28351959 GUARD AS1
283519810 GUARD AS1
5P107611 WASHER-HARD (13.5X30X4-MM THK)6
7X772912 WASHER (11X25X3-MM THK)28
8T412113 WASHER-HARD (11X21X2.5-MM THK)2
8T413314 NUT (M10X1.5-THD)2
8T413615 BOLT (M10X1.5X25-MM)22
8T417916 BOLT (M12X1.75X20-MM)6
8T419217 BOLT (M12X1.75X25-MM)6
8T419518 BOLT (M10X1.5X30-MM)6
8T422319 WASHER-HARD (13.5X25.5X3-MM THK)6
