System And Components
294-8030 GUARD GP-LINES -REAR FRAME, GRAPPLES/N 5351-UP
Group No: 294-8030 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1779381 | 1 PLATE | 1 | |
| 2007871 | 2 PLATE | 1 | |
| 2007872 | 3 PLATE | 1 | |
| 2008457 | 4 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2008458 | 5 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3002473 | 6 GUARD AS | 1 | |
| 2835195 | 7 GUARD AS | 1 | |
| 2835198 | 8 GUARD AS | 1 | |
| 2948031 | 9 PLATE AS | 1 | |
| 2948033 | 10 PLATE | 1 | |
| 2948237 | 11 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 5P1076 | 12 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 7X2489 | 13 BOLT (M24X3X100-MM) | 4 | |
| 7X7729 | 14 WASHER (11X25X3-MM THK) | 38 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 16 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 17 BOLT (M10X1.5X25-MM) | 28 | |
| 8T4167 | 18 WASHER-HARD (26X44X4-MM THK) | 8 | |
| 8T4179 | 19 BOLT (M12X1.75X20-MM) | 4 | |
| 8T4195 | 20 BOLT (M10X1.5X30-MM) | 6 | |
| 8T6380 | 21 BOLT (M24X3X130-MM) | 4 | |
| 8T4137 | 22 BOLT (M10X1.5X20-MM) | 4 |
