Assembly
100%

251-4736 HOOD & GUARD GPS/N 535274-606

Group No: 251-4736 · Commonality
Part NumberPart NameQty
4I39531 GROMMET1
35883262 HOOD AS (TOP)1
24987203 SUPPORT AS (LH)1
24991134 SUPPORT AS (RH)1
25001875 DOOR AS-ACCESS (HOOD SIDE, LH)1
25002166 DOOR AS-ACCESS (HOOD SIDE, RH)1
8T3597NUT-WELD (M12X1.75-THD)4
2499421HINGE2
25002207 PLATE AS1
25018998 PLATE1
25035549 STRIP2
251472611 SHEET (RH)1
251472813 SHEET (LH)1
251588714 PLATE1
254702515 PLATE AS1
255087916 SEAL1
255092717 PLATE1
281774419 LATCH AS2
281774520 LATCH AS2
282058321 PAWL4
5C726122 NUT (M8X1.25-THD)24
5P107623 WASHER-HARD (13.5X30X4-MM THK)27
5P411624 WASHER-HARD (8.8X20.5X2-MM THK)24
8T412126 WASHER-HARD (11X21X2.5-MM THK)17
8T413728 BOLT (M10X1.5X20-MM)17
8T413929 BOLT (M12X1.75X30-MM)27
8T424432 NUT (M12X1.75-THD)2
8T854933 LOCKNUT (M12X1.75-THD)2
340775834 SEAL1
8T419235 BOLT (M12X1.75X25-MM)2
8T908236 RIVET-POP16
337392837 SEAL4
337392938 SUPPORT-SEAL4
7D164939 WASHER-HARD (13.5X32X5-MM THK)2
322337640 PLATE AS1
