System And Components
200-1315 BRAKE GP-PARKINGS/N 5MY1-UP
Group No: 200-1315 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7F9579 | 1 SOCKET | 1 | |
| 7F9571 | 2 SCREW-ADJUSTMENT | 1 | |
| 7F9572 | 3 NUT (1/2-20-THD) | 1 | |
| 7F9578 | 4 SPRING | 1 | |
| 9M5138 | 5 PIN-ANCHOR | 2 | |
| 9M5137 | 6 BRACE-ANCHOR PIN | 1 | |
| 5D1242 | 7 BRACKET | 1 | |
| 6V8182 | 8 NUT (3/4-10-THD) | 2 | |
| 3B4512 | 9 LOCKWASHER | 2 | |
| 9M5139 | 10 SPRING | 2 | |
| 8W8673 | 11 SHOE AS-BRAKE | 2 | |
| 9M5140 | 12 PLATE AS | 1 | |
| 2001316 | 13 CAMSHAFT | 1 | |
| 8W8674 | KIT-BRAKE LINING |
