System And Components
283-9977 BRAKE GP-PARKINGS/N R1C1-UP; R1F1-UP; 5MY1-UP
Group No: 283-9977 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5D1242 | 1 BRACKET | 1 | |
| 7F9571 | 2 SCREW-ADJUSTMENT | 1 | |
| 7F9572 | 3 NUT (1/2-20-THD) | 1 | |
| 7F9578 | 4 SPRING | 1 | |
| 7F9579 | 5 SOCKET | 1 | |
| 9M5137 | 6 BRACE-ANCHOR PIN | 1 | |
| 9M5138 | 7 PIN-ANCHOR | 2 | |
| 9M5139 | 8 SPRING | 2 | |
| 9M5140 | 9 PLATE AS | 1 | |
| 2001316 | 10 CAMSHAFT | 1 | |
| 2839978 | 11 SHOE AS-BRAKE | 2 | |
| 3B4512 | 12 LOCKWASHER | 2 | |
| 6B6682 | 13 NUT-FULL (3/4-16-THD) | 2 | |
| 2839979 | KIT-BRAKE LINING | 1 |
