System And Components
260-1921 CONTROL GP-FOOT BRAKES/N 5351-UP
Group No: 260-1921 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1834184 | 1 ROLLER | 1 | |
| 3B4621 | 2 PIN-COTTER | 1 | |
| 6V3545 | 3 BEARING-ROLLER | 2 | |
| 9P9185 | 4 SPRING | 1 | |
| 9X1481 | 5 WASHER (13X25.4X1.6-MM THK) | 4 | |
| 1107595 | 6 PIN-SPRING | 1 | |
| 2601923 | 7 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1834216 | 8 PEDAL AS | 1 | |
| 1834183 | 9 SHAFT | 1 | |
| 1480775 | 10 SHAFT | 1 | |
| 1480776 | 11 PLATE | 1 | |
| 1501147 | 12 LINER | 1 | |
| 1501148 | 13 PLATE | 1 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4133 | 15 NUT (M10X1.5-THD) | 6 | |
| 8T4138 | 17 BOLT (M6X1X20-MM) | 6 | |
| 8T4186 | 18 BOLT (M10X1.5X40-MM) | 4 | |
| 9X8256 | 19 WASHER (6.6X12X2-MM THK) | 6 |
