System And Components
252-6538 CONTROL GP-PARKING BRAKES/N 5351-UP
Group No: 252-6538 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1712014 | 1 HOSE AS | 1 | |
| 1744312 | 2 SWITCH AS-PRESSURE (PARKING BRAKE OIL) | 1 | |
| 8T5677 | SLEEVE (0.6-M) | ||
| 5P6008 | TUBE-HEAT SHRINK (6.35-MM DIA)(0.2-M) | ||
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 2520742 | 3 MANIFOLD GP-CONTROL (PARKING BRAKE CONTROL) | 1 | |
| 2527105 | 4 TUBE AS | 1 | |
| 2527106 | 5 TUBE AS | 1 | |
| 2527107 | 6 TUBE AS | 1 | |
| 2556497 | 7 PLATE AS | 1 | |
| 1488313 | 8 ADAPTER AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 1488318 | 9 CONNECTOR AS | 3 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 1488371 | 10 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8C8988 | ELBOW | 1 | |
| 1488378 | 11 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 4D7794 | 12 CLIP | 2 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 14 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4191 | 15 BOLT (M10X1.5X16-MM) | 2 | |
| 8T5005 | 16 BOLT (M10X1.5X70-MM) | 2 | |
| 3J1907 | 17 SEAL-O-RING | 1 | |
| 6V8397 | 18 SEAL-O-RING | 1 |
