System And Components
252-6536 CONTROL GP-SERVICE BRAKES/N 5351-UP
Group No: 252-6536 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E7806 | 1 SWITCH AS-PRESSURE (BRAKE ACCUMULATOR CHARGE) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 6V0852 | 2 CAP-DUST | 2 | |
| 9U2886 | 3 VALVE GP-ACCUMULATOR CHARGING (BRAKE) | 1 | |
| 1488443 | 4 TEE AS | 2 | |
| 7X2459 | ADAPTER-TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1616861 | 5 HOSE AS | 1 | |
| 1645567 | 6 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1497155 | 7 HOSE AS | 1 | |
| 1838562 | 8 HOSE AS | 1 | |
| 2153685 | 9 VALVE GP-BRAKE CONTROL (SERVICE) | 1 | |
| 2388232 | 10 ACCUMULATOR GP-BRAKE (CHARGED)(FRONT) | 1 | |
| 2399941 | 11 ACCUMULATOR GP-BRAKE (CHARGED)(REAR) | 1 | |
| 2527096 | 12 HOSE AS | 1 | |
| 2527097 | 13 TUBE AS | 1 | |
| 2527098 | 14 TUBE AS | 1 | |
| 2527099 | 15 TUBE AS | 1 | |
| 2527100 | 16 TUBE AS | 1 | |
| 2527101 | 17 TUBE AS | 1 | |
| 3373703 | 18 BRACKET | 1 | |
| 2527103 | 19 BRACKET | 1 | |
| 2527104 | 20 MANIFOLD | 1 | |
| 1488313 | 21 ADAPTER AS | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1488318 | 22 CONNECTOR AS | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488336 | 23 CONNECTOR AS | 2 | |
| 6V8636 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488340 | 24 CONNECTOR AS | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488363 | 25 ELBOW AS | 1 | |
| 6V9876 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488365 | 26 ELBOW AS | 1 | |
| 8T6876 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488370 | 27 ELBOW AS | 2 | |
| 6V9851 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488374 | 28 ELBOW AS | 4 | |
| 6V8723 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488433 | 29 TEE AS | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 1488434 | 30 TEE AS | 1 | |
| 6V9843 | TEE | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 1504043 | 31 CONNECTOR AS | 3 | |
| 6V9873 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 3J1907 | 32 SEAL-O-RING | 1 | |
| 5M3062 | 33 BOLT (3/8-16X0.75-IN) | 2 | |
| 5S0581 | 34 WASHER-HARD (17X38X8-MM THK) | 1 | |
| 6D8305 | 35 CLAMP | 2 | |
| 8T4121 | 36 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4133 | 37 NUT (M10X1.5-THD) | 2 | |
| 8T4192 | 39 BOLT (M12X1.75X25-MM) | 3 | |
| 8T4223 | 40 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4896 | 41 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 8T4910 | 42 BOLT (M12X1.75X60-MM) | 1 | |
| 8T5005 | 43 BOLT (M10X1.5X70-MM) | 2 | |
| 1645624 | 44 ELBOW AS | 1 | |
| 9X2085 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488367 | 45 ELBOW AS | 1 | |
| 6V9850 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1544386 | KIT-REPAIR (ACCUMULATOR CHARGING VALVE) | 1 |
