System And Components
252-6549 LINES GP-SERVICE BRAKES/N 5351-499
Group No: 252-6549 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V0852 | 1 CAP-DUST | 2 | |
| 8C6416 | 2 FITTING | 2 | |
| 1945444 | 3 HOSE AS | 1 | |
| 1513832 | 4 TUBE AS | 2 | |
| 2272004 | 5 HOSE AS | 1 | |
| 2374147 | 6 HOSE AS | 1 | |
| 2633477 | 7 PLATE | 1 | |
| 2753589 | 8 HOSE AS | 1 | |
| 1488363 | 9 ELBOW AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9876 | ELBOW | 1 | |
| 1488367 | 10 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488371 | 11 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8C8988 | ELBOW | 1 | |
| 1488378 | 12 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488434 | 13 TEE AS | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9843 | TEE | 1 | |
| 1488435 | 14 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8781 | TEE | 1 | |
| 1488439 | 15 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8774 | TEE | 1 | |
| 1853365 | 16 UNION AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T0129 | UNION | 1 | |
| 1S0994 | 17 CLIP (LOOP) | 1 | |
| 5K5338 | 18 CLIP (LOOP) | 1 | |
| 6V8554 | 19 NUT (13/16-16-THD) | 2 | |
| 6V9169 | 20 NUT (13/16-16-THD) | 2 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 22 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4137 | 23 BOLT (M10X1.5X20-MM) | 1 |
