System And Components
252-6550 LINES GP-SERVICE BRAKES/N 535274-686
Group No: 252-6550 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V0852 | 1 CAP-DUST | 2 | |
| 8C6416 | 2 FITTING | 2 | |
| 1284197 | 3 HOSE AS | 1 | |
| 1487009 | 4 HOSE AS | 2 | |
| 1513832 | 5 TUBE AS | 1 | |
| 2533866 | 6 TUBE AS | 1 | |
| 2578478 | 7 HOSE AS | 1 | |
| 2591125 | 8 PLATE | 1 | |
| 2594781 | 9 HOSE AS | 1 | |
| 1488361 | 10 ELBOW AS (90-DEG) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9200 | ELBOW | 1 | |
| 1488363 | 11 ELBOW AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9876 | ELBOW | 1 | |
| 1488367 | 12 ELBOW AS | 4 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488377 | 13 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8980 | ELBOW | 1 | |
| 1488378 | 14 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488434 | 15 TEE AS | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9843 | TEE | 1 | |
| 1488439 | 16 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8774 | TEE | 1 | |
| 1564281 | 17 TEE AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 7X0838 | TEE-O-RING | 1 | |
| 1623052 | 18 ELBOW AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T0130 | ELBOW | 1 | |
| 1S0994 | 19 CLIP (LOOP) | 1 | |
| 6V8554 | 20 NUT (13/16-16-THD) | 2 | |
| 6V9168 | 21 NUT (11/16-16-THD) | 3 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4137 | 23 BOLT (M10X1.5X20-MM) | 2 |
