System And Components
257-8490 LINES GP-DECKING BLADES/N 535500-UP
Group No: 257-8490 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8K9176 | 1 CLAMP | 4 | |
| 1512071 | 2 HOSE AS | 2 | |
| 1515163 | 3 TUBE AS | 1 | |
| 1515337 | 4 TUBE AS | 1 | |
| 1646864 | 5 ELBOW AS | 4 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8T1810 | ELBOW | 1 | |
| 1751375 | 6 HOSE AS | 4 | |
| 2578480 | 7 HOSE AS | 1 | |
| 2578483 | 8 PLATE | 2 | |
| 3781583 | 9 TUBE AS | 1 | |
| 3781584 | 10 TUBE AS | 1 | |
| 3781585 | 11 TUBE AS | 1 | |
| 3781586 | 12 TUBE AS | 1 | |
| 2744311 | 13 HOSE AS | 1 | |
| 1488322 | 14 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8640 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488341 | 15 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488372 | 16 ELBOW AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8721 | ELBOW | 1 | |
| 1536256 | 17 ELBOW AS | 2 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8C7563 | ELBOW | 1 | |
| 1646860 | 18 TEE AS | 2 | |
| 6V9350 | TEE-BULKHEAD | 1 | |
| 7J9108 | SEAL-O-RING | 3 | |
| 1697409 | 19 UNION AS | 2 | |
| 6V8996 | UNION | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 6V8398 | 20 SEAL-O-RING | 2 | |
| 6V9169 | 21 NUT (13/16-16-THD) | 4 | |
| 6V9170 | 22 NUT-BULKHEAD (1-14-THD) | 4 | |
| 7X7729 | 23 WASHER (11X25X3-MM THK) | 6 | |
| 8T4121 | 24 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4133 | 25 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 26 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4195 | 27 BOLT (M10X1.5X30-MM) | 4 |
