System And Components
252-6561 LINES GP-GRAPPLE -DUAL FUNCTIONS/N 5351-279
Group No: 252-6561 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1257325 | 1 HOSE AS | 1 | |
| 1644160 | 2 HOSE AS | 2 | |
| 1644161 | 3 HOSE AS | 1 | |
| 1646871 | 6 ADAPTER AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1222222 | ADAPTER | 1 | |
| 2182359 | 7 HOSE AS | 1 | |
| 2052357 | 8 CONNECTOR AS | 3 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T7968 | CONNECTOR | 1 | |
| 2370957 | 9 SENSOR GP-PRESSURE (GRAPPLE OIL) | 1 | |
| 2588865 | 10 TUBE AS | 1 | |
| 2588866 | 11 TUBE AS | 1 | |
| 2588867 | 12 TUBE AS | 1 | |
| 2588868 | 13 TUBE AS | 1 | |
| 2681514 | 14 UNION AS | 2 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8C8493 | UNION | 1 | |
| 2929798 | 15 HOSE AS | 4 | |
| 1488312 | 16 ADAPTER AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 3T4965 | ADAPTER | 1 | |
| 1488317 | 17 CONNECTOR AS | 2 | |
| 6V8714 | CONNECTOR | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 1488328 | 18 CONNECTOR AS | 3 | |
| 6V8633 | CONNECTOR | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488340 | 19 CONNECTOR AS | 2 | |
| 6V8639 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488352 | 20 ELBOW AS | 2 | |
| 6V9854 | ELBOW (SWIVEL) | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 1488353 | 21 ELBOW AS (45-DEG) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488364 | 22 ELBOW AS | 6 | |
| 6V8625 | ELBOW (90-DEG) | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488367 | 23 ELBOW AS | 2 | |
| 6V9850 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488370 | 24 ELBOW AS | 1 | |
| 6V9851 | ELBOW (SWIVEL) | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488415 | 25 REDUCER AS | 2 | |
| 6V8936 | REDUCER | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1495452 | 26 UNION AS (STRAIGHT) | 2 | |
| 6V8994 | UNION (STRAIGHT) | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 1504037 | 27 TEE AS | 4 | |
| 6V9844 | TEE-SWIVEL | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1536241 | 28 ELBOW AS | 2 | |
| 8C8989 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1536248 | 29 ADAPTER AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T6663 | ADAPTER-PORT | 1 | |
| 2053079 | 30 ADAPTER | 1 | |
| 1S0994 | 31 CLIP (LOOP) | 1 | |
| 2P1293 | 32 LOCKNUT (1-3/16-12-THD) | 2 | |
| 6M5062 | 33 SEAL-O-RING | 1 | |
| 6V5758 | 34 SEAL-O-RING | 1 | |
| 6V9168 | 35 NUT (11/16-16-THD) | 2 | |
| 7X7729 | 36 WASHER (11X25X3-MM THK) | 2 | |
| 8T4121 | 37 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 38 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 39 BOLT (M10X1.5X25-MM) | 3 | |
| 9X8250 | 40 CLIP (LOOP) | 1 |
