System And Components
252-6534 LINES GP-HYDRAULICS/N 535274-UP
Group No: 252-6534 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V0852 | 1 CAP-DUST | 2 | |
| 8T4984 | 2 CLAMP-HOSE | 2 | |
| 9U4098 | 3 ELBOW | 1 | |
| 1321204 | 4 VALVE GP-CHECK (PILOT) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488443 | 5 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 7X2459 | ADAPTER-TEE | 1 | |
| 1497136 | 6 HOSE AS | 1 | |
| 1645567 | 7 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 1645576 | 8 ADAPTER AS | 1 | |
| 6V8926 | ADAPTER | 1 | |
| 8T7876 | SEAL-O-RING | 1 | |
| 1645590 | 9 VALVE AS-FLUID SAMPLING (HYDRAULIC OIL) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 8C3446 | VALVE-SAMPLING | 1 | |
| 1647005 | 10 HOSE AS | 1 | |
| 1725761 | 11 TEE AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1268306 | TEE-O-RING | 1 | |
| 1914904 | 12 HOSE AS | 1 | |
| 1922684 | 13 VALVE AS-CHECK (PILOT) | 1 | |
| 1526902 | 14 FILTER-OIL (ADVANCED EFFICIENCY) | 1 | |
| 2403454 | 15 PLATE | 1 | |
| 2416215 | 16 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8076 | ELBOW | 1 | |
| 2526576 | 17 TUBE AS | 1 | |
| 2526577 | 18 TUBE AS | 1 | |
| 2526578 | 19 TUBE AS | 1 | |
| 2526579 | 20 TUBE AS | 1 | |
| 2526580 | 21 TUBE AS | 1 | |
| 2527125 | 22 TUBE AS | 1 | |
| 2537537 | 23 VALVE GP-CHECK (PILOT) | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 2609189 | 24 ELBOW AS-SWIVEL | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1248333 | ELBOW | 1 | |
| 2609190 | 25 TEE AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 2526575 | TEE | 1 | |
| 2668954 | 26 FILTER GP-OIL (HYDRAULIC) | 1 | |
| 2010875 | FILTER-OIL (ADVANCED EFFICIENCY) | 1 | |
| 1488305 | 27 ADAPTER AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5P9617 | ADAPTER | 1 | |
| 1488353 | 28 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488352 | 29 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9854 | ELBOW (SWIVEL) | 1 | |
| 1488354 | 30 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9002 | ELBOW | 1 | |
| 1488356 | 31 ELBOW AS | 3 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 6V9009 | ELBOW | 1 | |
| 1488364 | 32 ELBOW AS | 3 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 3273766 | 33 HOSE | 1 | |
| 1488370 | 34 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9851 | ELBOW | 1 | |
| 1488381 | 35 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T5429 | ELBOW | 1 | |
| 1488406 | 36 PLUG AS | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 1488452 | 37 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 8T2363 | TEE-UNION | 1 | |
| 1557321 | 38 ADAPTER AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V1722 | ADAPTER | 1 | |
| 1645594 | 39 CONNECTOR AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8C5723 | CONNECTOR | 1 | |
| 1P4577 | 40 FLANGE-HALF | 2 | |
| 4J0520 | 41 SEAL-O-RING | 1 | |
| 4J0527 | 42 SEAL-O-RING | 1 | |
| 5S7382 | 43 BOLT (3/8-16X1.375-IN) | 4 | |
| 6V5839 | 44 WASHER (11X21X2.5-MM THK) | 8 | |
| 7X0325 | 45 BOLT (1/2-13X2.5-IN) | 2 | |
| 8C3451 | 46 CAP-DUST (HYDRAULIC OIL) | 1 | |
| 8C4436 | 47 BOLT (1/2-13X1.375-IN) | 2 | |
| 8T4137 | 48 BOLT (M10X1.5X20-MM) | 8 | |
| 8T4223 | 49 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4896 | 50 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 1504027 | 51 TEE AS | 1 | |
| 3E2310 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488367 | 52 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 |
