System And Components
252-6537 LINES GP-PILOTS/N 535337-363
Group No: 252-6537 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V0852 | 1 CAP-DUST | 2 | |
| 1005151 | 2 COUPLING-SHAFT | 1 | |
| 1645567 | 3 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 2147568 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 1708531 | 4 ACCUMULATOR GP-PILOT OIL (CHARGED)(DEAD ENGINE LOWER, ARCH, BOOM) | 1 | |
| 1904372 | 5 HOSE AS | 1 | |
| 2140736 | 6 HOSE AS | 1 | |
| 2514315 | 7 PUMP GP-GEAR (PILOT) | 1 | |
| 2527109 | 8 TUBE AS | 1 | |
| 2527110 | 9 TUBE AS | 1 | |
| 3314999 | 10 HOSE AS | 1 | |
| 3318167 | 11 VALVE GP-PILOT (DIFFERENTIAL LOCK) | 1 | |
| 1488326 | 12 CONNECTOR AS | 2 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9872 | CONNECTOR | 1 | |
| 1488335 | 13 CONNECTOR AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488336 | 14 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488362 | 15 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T6684 | ELBOW | 1 | |
| 1488367 | 16 ELBOW AS | 3 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488372 | 17 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8721 | ELBOW | 1 | |
| 1488374 | 18 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8723 | ELBOW | 1 | |
| 1488434 | 19 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9843 | TEE | 1 | |
| 1504043 | 20 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9873 | CONNECTOR | 1 | |
| 1536246 | 21 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 3 | |
| 7X0820 | TEE | 1 | |
| 1S0994 | 22 CLIP (LOOP) | 2 | |
| 2J5245 | 23 BOLT (3/8-16X1.25-IN) | 2 | |
| 3D2824 | 24 SEAL-O-RING | 1 | |
| 6V1867 | 25 CLIP (SLOT) | 1 | |
| 6V1868 | 26 CLIP (TAB) | 1 | |
| 6V1869 | 27 GROMMET (65-MM ID) | 1 | |
| 6V9168 | 28 NUT (11/16-16-THD) | 1 | |
| 8C3089 | 29 SEAL-O-RING | 1 | |
| 8M2773 | 30 CLIP (LOOP) | 1 | |
| 8T4121 | 31 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4137 | 32 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4139 | 33 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4172 | 34 BOLT (M10X1.5X80-MM) | 2 | |
| 8T4191 | 35 BOLT (M10X1.5X16-MM) | 2 | |
| 8T4223 | 36 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4896 | 37 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 |
