System And Components
252-6537 LINES GP-PILOTS/N 535274-UP
Group No: 252-6537 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N8744 | 1 MOUNT | 3 | |
| 6R5056 | 2 HOSE AS | 1 | |
| 6V0852 | 3 CAP-DUST | 2 | |
| 1005151 | 4 COUPLING-SHAFT | 1 | |
| 1645567 | 5 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 2147568 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 1708531 | 6 ACCUMULATOR GP-PILOT OIL (CHARGED) | 1 | |
| 1904372 | 7 HOSE AS | 1 | |
| 2514315 | 8 PUMP GP-GEAR (PILOT) | 1 | |
| 2522381 | 9 HOSE AS | 1 | |
| 2527109 | 10 TUBE AS | 1 | |
| 3318167 | 11 VALVE GP-PILOT (DIFFERENTIAL LOCK) | 1 | |
| 2915240 | 12 HOSE AS | 1 | |
| 3609896 | 13 PLATE AS | 1 | |
| 0993649 | 14 BOLT (M8X1.25X40-MM) | 3 | |
| 1325789 | 15 CLIP (LADDER) | 1 | |
| 1488326 | 16 CONNECTOR AS | 2 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9872 | CONNECTOR | 1 | |
| 1488335 | 17 CONNECTOR AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488336 | 18 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488362 | 19 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T6684 | ELBOW | 1 | |
| 1488367 | 20 ELBOW AS | 3 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488371 | 22 ELBOW AS | 1 | |
| 8C8988 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488372 | 23 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8721 | ELBOW | 1 | |
| 1488374 | 24 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8723 | ELBOW | 1 | |
| 1488434 | 25 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9843 | TEE | 1 | |
| 1536246 | 27 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 3 | |
| 7X0820 | TEE | 1 | |
| 1S0994 | 28 CLIP (LOOP) | 2 | |
| 2J5245 | 29 BOLT (3/8-16X1.25-IN) | 2 | |
| 3D2824 | 30 SEAL-O-RING | 1 | |
| 5C7261 | 31 NUT (M8X1.25-THD) | 6 | |
| 6V1867 | 32 CLIP (SLOT) | 1 | |
| 6V1868 | 33 CLIP (TAB) | 1 | |
| 6V1869 | 34 GROMMET (65-MM ID) | 1 | |
| 6V9168 | 35 NUT (11/16-16-THD) | 1 | |
| 7X0603 | 36 WASHER-HARD (9.9X35X2.5-MM THK) | 6 | |
| 8C3089 | 37 SEAL-O-RING | 1 | |
| 8T4121 | 38 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4139 | 39 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4172 | 40 BOLT (M10X1.5X80-MM) | 2 | |
| 8T4191 | 41 BOLT (M10X1.5X16-MM) | 2 | |
| 8T4223 | 42 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4224 | 43 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T4896 | 44 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 |
