System And Components
563-2866 ROTATING GP-MOTORS/N 535354-UP
Group No: 563-2866 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1504561 | 1 PIN-ROLL | 6 | |
| 2408660 | 2 BOLT (M12X1.75X180-MM) | 10 | |
| 3975637 | 3 STATOR (LOWER) | 1 | |
| 3976871 | 4 PLUG | 2 | |
| 1729906 | 5 VANE | 9 | |
| 1504559 | 6 SPRING | 27 | |
| 1504557 | 7 SHAFT-MOTOR | 1 | |
| 2193560 | 8 VALVE | 2 | |
| 3975619 | 9 FRAME-STATOR | 1 | |
| 3975639 | 10 STATOR (UPPER) | 1 | |
| 1504562 | 11 SCREW | 2 | |
| 5175262 | KIT-SEAL (MOTOR) | 1 |
