System And Components
252-5205 LINES GP-WINCHS/N 535579-UP
Group No: 252-5205 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V0852 | 1 CAP-DUST | 1 | |
| 1488424 | 2 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T8902 | ADAPTER-TEE | 1 | |
| 2576364 | 3 VALVE & MTG GP-SOLENOID (24-VOLT)(WINCH FREESPOOL BRAKE RELEASE) | 1 | |
| 2415895 | VALVE GP-SOLENOID (24-VOLT)(WINCH FREESPOOL BRAKE RELEASE) | 1 | |
| 2506148 | COIL AS (24-VOLT) | 1 | |
| 3821310 | 4 TUBE AS | 1 | |
| 3821309 | 5 TUBE AS | 1 | |
| 2588981 | 6 TUBE AS | 1 | |
| 2588984 | 7 PLATE AS | 1 | |
| 3116887 | 8 TUBE AS | 1 | |
| 1488327 | 9 CONNECTOR AS | 2 | |
| 6V8637 | CONNECTOR | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488347 | 10 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488360 | 11 ELBOW AS | 1 | |
| 6V9182 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488371 | 12 ELBOW AS | 1 | |
| 8C8988 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488378 | 13 ELBOW AS | 2 | |
| 6V8724 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488381 | 14 ELBOW AS | 1 | |
| 8T5429 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488435 | 15 TEE AS | 1 | |
| 6V8781 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 1488444 | 16 TEE AS-SWIVEL | 2 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1504043 | 17 CONNECTOR AS | 1 | |
| 6V9873 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1645567 | 18 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6D4246 | 19 CLIP (LOOP) | 2 | |
| 8T4121 | 20 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 21 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4195 | 22 BOLT (M10X1.5X30-MM) | 1 | |
| 9X2480 | 23 BOLT (M6X1X45-MM) | 2 | |
| 9X8256 | 24 WASHER (6.6X12X2-MM THK) | 2 |
