System And Components
271-9087 LINES GP-WINCHS/N 535500-UP
Group No: 271-9087 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1048598 | 1 HOSE AS | 1 | |
| 1470178 | 2 FILTER GP-OIL (WINCH) | 1 | |
| 1529074 | 3 HOSE AS | 1 | |
| 2395031 | 4 BRACKET | 1 | |
| 2520796 | 5 PUMP GP-GEAR (PILOT, WINCH) | 1 | |
| 2533869 | 6 BRACKET | 1 | |
| 2719089 | 7 HOSE AS | 1 | |
| 2719090 | 8 HOSE AS | 1 | |
| 1488336 | 9 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488345 | 10 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 1488347 | 11 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488358 | 12 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8624 | ELBOW | 1 | |
| 1488367 | 13 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488374 | 14 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8723 | ELBOW | 1 | |
| 1488381 | 15 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T5429 | ELBOW | 1 | |
| 1488406 | 16 PLUG AS | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 1540273 | 17 CLIP | 1 | |
| 1645616 | 18 PLUG AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 9S6130 | PLUG | 1 | |
| 1S0994 | 19 CLIP (LOOP) | 1 | |
| 5P1076 | 20 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 6V9829 | 21 CAP (ORFS) | 1 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4133 | 23 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 24 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4137 | 25 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4179 | 26 BOLT (M12X1.75X20-MM) | 1 | |
| 8T4223 | 27 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4244 | 28 NUT (M12X1.75-THD) | 2 |
