System And Components
305-2640 LINES GP-WATER -TURBOS/N WPN1640-UP
Group No: 305-2640
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2M3881 | 1 LUG | 4 | |
| 5P5613 | 2 CROSS-FLARED | 1 | |
| 7F2050 | 3 LOCKNUT (3/4-16-THD) | 1 | |
| 7N3368 | 4 GASKET | 1 | |
| 7N7878 | 5 PLATE-COVER | 2 | |
| 1442980 | 6 HOUSING | 1 | |
| 1805044 | 7 COVER | 2 | |
| 3419211 | 8 GASKET | 4 | |
| 2470708 | 9 SEAL-O-RING | 2 | |
| 3052650 | 10 TUBE AS | 1 | |
| 3052651 | 11 TUBE AS | 1 | |
| 3052652 | 12 TUBE AS | 1 | |
| 3052653 | 13 TUBE AS | 1 | |
| 3052654 | 14 TUBE AS | 1 | |
| 3052658 | 15 BRACKET | 1 | |
| 3391105 | 16 TUBE AS | 1 | |
| 3391106 | 17 PLATE | 1 | |
| 0043099 | 18 CONNECTOR | 1 | |
| 0054173 | 19 ELBOW | 1 | |
| 0L2070 | 20 BOLT (3/8-16X2.25-IN) | 3 | |
| 0S1594 | 21 BOLT (3/8-16X1-IN) | 1 | |
| 2A4639 | 22 BOLT (3/8-16X1.625-IN) | 8 | |
| 2M9780 | 23 SEAL-O-RING | 3 | |
| 2P1281 | 24 ADAPTER-STRAINER | 1 | |
| 3R9704 | 25 ELBOW | 1 | |
| 5M2894 | 26 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 9S4190 | 27 PLUG-O-RING (7/8-14-THD) | 1 | |
| 5P9299 | 28 CLIP (LOOP) | 1 | |
| 6K3607 | 29 CONNECTOR | 1 | |
| 7L7262 | 30 ELBOW-FLARED | 1 | |
| 8M0744 | 31 NUT-FLARED (1-1/16-12-THD) | 3 | |
| 8M0745 | 32 REDUCER-FLARED | 3 | |
| 8M0755 | 33 ADAPTER | 1 | |
| 8T6761 | 35 PLUG-PIPE (1-11-1/2 NPT THD) | 2 | |
| 9S8752 | 36 NUT-FULL (3/8-16-THD) | 1 | |
| 1L5081 | 37 SPACER (0.41X0.75X0.56-IN THK) | 4 |
