System And Components
305-2616 MANIFOLD GP-EXHAUST -WATER COOLEDS/N WPN1500-1665
Group No: 305-2616
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1L4473 | 1 BUSHING-TERMINAL | 4 | |
| 1W7810 | 2 GASKET-OUTLET | 1 | |
| 4W1478 | 3 SEAL GP-EXHAUST | 1 | |
| 6L3143 | 4 BOLT-HIGH TEMPERATURE (1/2-13X3-IN) | 4 | |
| 7E4127 | 5 GASKET | 8 | |
| 7W2124 | 6 BRACKET | 2 | |
| 9V0999 | 7 SPACER (13.8X30X50-MM THK) | 4 | |
| 1091086 | 8 SPACER (18.5X29X6-MM THK) | 1 | |
| 1215736 | 9 GASKET (TURBOCHARGER) | 1 | |
| 1339315 | 10 CLAMP-BAND | 1 | |
| 8T0122 | NUT-FULL (1/4-28-THD) | 1 | |
| 1350171 | 11 SEAL-EXHAUST | 1 | |
| 1350172 | 12 RING-EXHAUST SEAL | 1 | |
| 1411732 | 13 HOUSING-EXHAUST BYPASS | 1 | |
| 1411747 | 14 SHIELD | 1 | |
| 1411751 | 15 GASKET | 1 | |
| 9X8873 | 16 BOLT (1/2-13X2.25-IN) | 4 | |
| 3307327 | 17 BELLOWS AS | 2 | |
| 2193234 | 18 SEAL GP-EXHAUST | 1 | |
| 2295333 | 19 SEAL | 6 | |
| 2453512 | 20 GASKET (EXHAUST) | 1 | |
| 3039357 | 21 COUPLING | 1 | |
| 3052617 | 22 MANIFOLD AS | 1 | |
| 3052618 | 23 MANIFOLD AS | 1 | |
| 3052620 | 24 ELBOW-EXHAUST | 2 | |
| 3052621 | 25 ELBOW-EXHAUST | 1 | |
| 3052635 | 26 BRACKET AS | 1 | |
| 3136932 | 27 BRACKET AS | 1 | |
| 3065169 | 28 ELBOW AS-EXHAUST | 1 | |
| 3083813 | 29 BRACKET AS | 1 | |
| 3136930 | 30 BRACKET AS | 1 | |
| 3116494 | 31 ELBOW-EXHAUST | 1 | |
| 0L2070 | 32 BOLT (3/8-16X2.25-IN) | 16 | |
| 0S1587 | 33 BOLT (1/2-13X1.75-IN) | 2 | |
| 0S1588 | 34 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1591 | 35 BOLT (3/8-16X1.5-IN) | 8 | |
| 0V0375 | 36 BOLT (1/2-13X3.25-IN) | 4 | |
| 1683349 | 37 PLUG-PIPE | 4 | |
| 1687800 | 38 LOCKNUT (3/8-16-THD) | 4 | |
| 1A1460 | 39 BOLT (1/2-13X2-IN) | 3 | |
| 1D4706 | 40 BOLT (3/8-16X6-IN) | 16 | |
| 1F7958 | 41 NUT-FULL (1/2-13-THD) | 8 | |
| 3139550 | 42 STUD-TAPERLOCK (3/8-16X2.165-IN) | 8 | |
| 2N9288 | 43 STUD-TAPERLOCK (3/8-16X1.67-IN) | 4 | |
| 3E2331 | 44 PLUG (M18X1.5-THD) | 1 | |
| 3E6916 | 45 NUT-FULL (3/8-16-THD) | 30 | |
| 4J4382 | 46 PLUG-PIPE (1/2-14-THD) | 2 | |
| 5M2894 | 47 WASHER-HARD (10.2X18.5X2.5-MM THK) | 44 | |
| 5P2603 | 48 STUD-TAPERLOCK (3/8-16X1.57-IN) | 4 | |
| 5P7128 | 49 BOLT-HIGH TEMPERATURE (3/8-16X2-IN) | 2 | |
| 5P8245 | 50 WASHER-HARD (13.5X25.5X3-MM THK) | 32 | |
| 6V3631 | 51 NUT-FULL (1/2-13-THD) | 4 | |
| 7L6443 | 52 BOLT-HIGH TEMPERATURE (3/8-16X2.25-IN) | 18 | |
| 8C8491 | 53 WASHER-HARD (10.2X22X3-MM THK) | 44 | |
| 8M2295 | 54 BOLT (3/8-16X1.625-IN) | 2 | |
| 8T6761 | 55 PLUG-PIPE (1-11-1/2 NPT THD) | 3 | |
| 8T6765 | 56 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9S1366 | 57 BOLT (1/2-13X2.5-IN) | 1 | |
| 9S1374 | 58 BOLT (1/2-13X8-IN) | 2 | |
| 9S8752 | 59 NUT-FULL (3/8-16-THD) | 10 |
