System And Components
290-3419 REGULATOR GP-GAS PRESSURES/N WPN1-1622
Group No: 290-3419
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3872 | 1 SUPPORT | 2 | |
| 1W8129 | 2 SUPPORT | 1 | |
| 2W2243 | 3 CLAMP | 4 | |
| 3B6486 | 4 CAP-PIPE | 1 | |
| 3R5387 | 5 CONNECTOR | 1 | |
| 4B7770 | 6 TEE | 1 | |
| 5P8116 | 7 ELBOW-FLARED | 1 | |
| 6I0327 | 8 ADAPTER | 1 | |
| 6L2849 | 9 JOINT AS-TUBE | 2 | |
| 9X7521 | SEAL | 2 | |
| 6S7721 | 10 LEVER | 1 | |
| 6V9163 | 11 ROD END (BEARING) | 1 | |
| 7E3407 | 12 REGULATOR AS-GAS PRESSURE | 1 | |
| 7E9748 | 13 ROD END (BEARING) | 1 | |
| 7N6986 | 14 SUPPORT | 1 | |
| 8T6764 | 15 PLUG-PIPE (1/8-27-THD) | 1 | |
| 0619593 | 16 ADAPTER | 1 | |
| 0910081 | 17 SPACER (10.5X20X10-MM THK) | 8 | |
| 1059267 | 18 ADAPTER | 1 | |
| 1076318 | 19 VALVE GP-FUEL RATIO | 1 | |
| 1149269 | 20 SLEEVE | 2 | |
| 1640433 | 21 PLATE | 1 | |
| 1756830 | 22 ROD | 1 | |
| 2541115 | 23 ACTUATOR | 1 | |
| 2635007 | 24 LEVER-THROTTLE | 1 | |
| 2958941 | 25 BRACKET AS | 1 | |
| 2903410 | 26 TUBE AS | 1 | |
| 2903411 | 27 TUBE AS | 1 | |
| 0S1571 | 28 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1587 | 29 BOLT (1/2-13X1.75-IN) | 4 | |
| 0S1591 | 30 BOLT (3/8-16X1.5-IN) | 6 | |
| 0S1619 | 31 BOLT (3/8-16X3-IN) | 2 | |
| 0T0055 | 32 BOLT (3/8-16X4.25-IN) | 2 | |
| 1A2029 | 33 BOLT (3/8-16X1.125-IN) | 2 | |
| 1A5822 | 34 BOLT (1/2-13X2.75-IN) | 4 | |
| 1P4579 | 35 FLANGE-HALF | 2 | |
| 3B1915 | 36 BOLT (3/8-16X1.375-IN) | 2 | |
| 3J7354 | 37 SEAL-O-RING | 1 | |
| 3K0360 | 38 SEAL-O-RING | 1 | |
| 1B7182 | 39 BOLT (5/16-18X1.25-IN) | 3 | |
| 4B9029 | 40 NIPPLE-PIPE | 1 | |
| 4F2294 | 41 NUT-JAM (5/16-24-THD) | 1 | |
| 4J0524 | 42 SEAL-O-RING | 1 | |
| 5M2894 | 43 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 5P0537 | 44 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 5P8245 | 45 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5S0003 | 46 NUT (5/16-18-THD) | 2 | |
| 6B3156 | 47 NIPPLE-PIPE | 1 | |
| 6V2317 | 48 BOLT (M8X1.25X30-MM) | 4 | |
| 8L4496 | 49 NUT-JAM (5/16-24 LH-THD) | 1 | |
| 8M9024 | 50 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 9F7022 | 51 BOLT (1/4-20X1.5-IN) | 4 | |
| 9M1974 | 52 WASHER-HARD (8.8X16X2-MM THK) | 9 | |
| 9S4182 | 53 PLUG (7/16-20-THD) | 1 | |
| 9S4185 | 54 PLUG (3/4-16-THD) | 1 | |
| 9S8750 | 55 NUT-FULL (1/4-20-THD) | 4 | |
| 9S8752 | 56 NUT-FULL (3/8-16-THD) | 7 |
