System And Components
311-6490 REGULATOR GP-GAS PRESSURES/N WPT1548-UP
Group No: 311-6490
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3872 | 1 SUPPORT | 2 | |
| 1W8129 | 2 SUPPORT | 2 | |
| 3B6486 | 3 CAP-PIPE | 1 | |
| 3B7749 | 4 NIPPLE-PIPE | 1 | |
| 4B7770 | 5 TEE | 1 | |
| 6I0327 | 6 ADAPTER | 1 | |
| 6L2849 | 7 JOINT AS-TUBE | 2 | |
| 9X7521 | SEAL | 2 | |
| 6S7721 | 8 LEVER | 1 | |
| 6V1760 | 9 ELBOW-FLARED | 1 | |
| 6V9163 | 10 ROD END (BEARING) | 1 | |
| 7C9082 | 11 ADAPTER | 1 | |
| 7E9748 | 12 ROD END (BEARING) | 1 | |
| 8D8414 | 13 CLAMP | 4 | |
| 0910081 | 14 SPACER (10.5X20X10-MM THK) | 8 | |
| 1062448 | 15 TUBE AS | 1 | |
| 1062449 | 16 TUBE AS | 1 | |
| 1076318 | 17 VALVE GP-FUEL RATIO | 1 | |
| 1149269 | 18 SLEEVE | 2 | |
| 1195092 | 19 ROD | 1 | |
| 1640433 | 20 PLATE | 1 | |
| 2635007 | 21 LEVER-THROTTLE | 1 | |
| 2700378 | 22 BRACKET | 1 | |
| 3305584 | 23 ACTUATOR | 1 | |
| 3355764 | 24 REGULATOR AS-GAS PRESSURE | 1 | |
| 0094440 | 25 CONNECTOR | 1 | |
| 1653931 | 26 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1587 | 27 BOLT (1/2-13X1.75-IN) | 4 | |
| 1653929 | 28 BOLT (3/8-16X1.5-IN) | 4 | |
| 0S1594 | 29 BOLT (3/8-16X1-IN) | 2 | |
| 1A5964 | 30 BOLT (3/8-16X4.5-IN) | 2 | |
| 0S1619 | 31 BOLT (3/8-16X3-IN) | 2 | |
| 0L1329 | 32 BOLT (1/2-13X3-IN) | 4 | |
| 1B7182 | 33 BOLT (5/16-18X1.25-IN) | 3 | |
| 1P4579 | 34 FLANGE-HALF | 2 | |
| 3B1915 | 35 BOLT (3/8-16X1.375-IN) | 4 | |
| 3J7354 | 36 SEAL-O-RING | 1 | |
| 3K0360 | 37 SEAL-O-RING | 1 | |
| 4F2294 | 38 NUT-JAM (5/16-24-THD) | 1 | |
| 4J0524 | 39 SEAL-O-RING | 1 | |
| 5M2894 | 40 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 5P0537 | 41 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 5P8245 | 42 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 5S0003 | 43 NUT (5/16-18-THD) | 2 | |
| 6B3156 | 44 NIPPLE-PIPE | 1 | |
| 6V5218 | 45 BOLT (M8X1.25X35-MM) | 4 | |
| 8L4496 | 46 NUT-JAM (5/16-24 LH-THD) | 1 | |
| 8T6765 | 47 PLUG-PIPE (1/4-18-THD) | 2 | |
| 9F7022 | 48 BOLT (1/4-20X1.5-IN) | 4 | |
| 9M1974 | 49 WASHER-HARD (8.8X16X2-MM THK) | 9 | |
| 9S4182 | 50 PLUG (7/16-20-THD) | 1 | |
| 9S4185 | 51 PLUG (3/4-16-THD) | 1 | |
| 9S8750 | 52 NUT-FULL (1/4-20-THD) | 4 | |
| 9S8752 | 53 NUT-FULL (3/8-16-THD) | 7 |
