System And Components
377-9669 LINES GP-TURBOCHARGER OILFIELD INSTALLATION
Group No: 377-9669
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W7214 | 1 ELBOW-DRAIN | 2 | |
| 4P0692 | 2 CLAMP AS | 2 | |
| 6I0804 | 3 ADAPTER-TURBOCHARGER OIL | 2 | |
| 6V9809 | 4 ELBOW | 1 | |
| 7N7559 | 5 GASKET | 2 | |
| 9Y5814 | 6 ELBOW-DRAIN | 2 | |
| 2528374 | 7 GASKET | 2 | |
| 3779670 | 8 HOSE AS | 1 | |
| 3779671 | 9 HOSE AS | 1 | |
| 3779672 | 10 TUBE | 1 | |
| 3779673 | 11 TUBE | 1 | |
| 3779674 | 12 TUBE AS | 1 | |
| 3783283 | 13 BRACKET | 1 | |
| 3982215 | 14 BRACKET | 1 | |
| 0L2070 | 15 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S1594 | 16 BOLT (3/8-16X1-IN) | 4 | |
| 0S1608 | 17 BOLT (3/8-16X3.75-IN) | 2 | |
| 1123540 | 18 SEAL-O-RING | 4 | |
| 1F7958 | 19 NUT-FULL (1/2-13-THD) | 2 | |
| 2287091 | 20 SEAL-O-RING | 2 | |
| 2815975 | 21 ELBOW AS | 1 | |
| 6V8626 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2A4639 | 22 BOLT (3/8-16X1.625-IN) | 4 | |
| 3196217 | 23 CONNECTOR AS | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3218653 | 24 CONNECTOR AS | 1 | |
| 8T1687 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3309772 | 25 ELBOW AS | 1 | |
| 6V8624 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3B1915 | 26 BOLT (3/8-16X1.375-IN) | 2 | |
| 4K8302 | 27 CLIP (LOOP) | 2 | |
| 4P4460 | 28 GASKET | 2 | |
| 5M2894 | 29 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 5P8245 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6H1717 | 31 BOLT (1/2-13X1.125-IN) | 2 | |
| 8S9191 | 32 BOLT (3/8-16X4-IN) | 4 | |
| 9S8752 | 33 NUT-FULL (3/8-16-THD) | 4 |
