System And Components
377-9675 LINES GP-AUXILIARY FRESH WATERFIELD INSTALLATION
Group No: 377-9675
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3P6061 | 1 GASKET | 1 | |
| 4N1418 | 2 GASKET-RADIATOR INLET | 2 | |
| 7W1446 | 3 ELBOW | 1 | |
| 7W3297 | 4 ELBOW | 1 | |
| 8T2657 | 5 JOINT AS-TUBE | 6 | |
| 9X7529 | SEAL | 1 | |
| 1839579 | 6 PLATE | 2 | |
| 2308986 | 7 BRACKET | 2 | |
| 3779676 | 8 TUBE AS | 1 | |
| 3779677 | 9 TUBE AS | 1 | |
| 3779678 | 10 TUBE | 1 | |
| 0L1143 | 11 BOLT (3/8-16X2.5-IN) | 1 | |
| 1653929 | 12 BOLT (3/8-16X1.5-IN) | 4 | |
| 0S1594 | 13 BOLT (3/8-16X1-IN) | 4 | |
| 1303374 | 14 CLIP | 6 | |
| 1A2029 | 15 BOLT (3/8-16X1.125-IN) | 2 | |
| 1A5964 | 16 BOLT (3/8-16X4.5-IN) | 2 | |
| 1B9575 | 17 BOLT (5/16-18X1.56-IN) | 1 | |
| 3B1915 | 18 BOLT (3/8-16X1.375-IN) | 8 | |
| 4F7387 | 19 SEAL-O-RING | 1 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 8T1296 | 21 WASHER (10.5X19X3.5-MM THK) | 2 | |
| 8T6765 | 22 PLUG-PIPE (1/4-18-THD) | 2 | |
| 9S8752 | 23 NUT-FULL (3/8-16-THD) | 8 |
