System And Components
377-9682 LINES GP-WATERJACKET WATER
Group No: 377-9682
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4W0530 | 1 RING-RETAINING | 2 | |
| 4W0531 | 2 RETAINER | 4 | |
| 1424280 | 3 HOUSING | 1 | |
| 1539963 | 4 RING | 2 | |
| 1571435 | 5 CLAMP | 4 | |
| 1571437 | 6 BRACKET | 4 | |
| 1600122 | 7 ELBOW | 1 | |
| 1895779 | 8 ELBOW | 1 | |
| 3779683 | 9 TUBE AS | 1 | |
| 3779686 | 10 BRACKET | 2 | |
| 3893880 | 11 TUBE AS | 1 | |
| 0S0509 | 12 BOLT (3/8-16X0.75-IN) | 8 | |
| 0S1588 | 13 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1594 | 14 BOLT (3/8-16X1-IN) | 8 | |
| 1A2029 | 15 BOLT (3/8-16X1.125-IN) | 6 | |
| 1A5183 | 16 BOLT (3/8-16X4.75-IN) | 2 | |
| 2D4534 | 17 BOLT-SOCKET HEAD (3/8-16X1-IN) | 2 | |
| 3P0815 | 18 SEAL-O-RING | 1 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 26 | |
| 6V1581 | 20 CLIP (SLOT) | 2 | |
| 6V1582 | 21 CLIP (TAB) | 2 | |
| 6V5066 | 22 SEAL-O-RING | 1 | |
| 8T1919 | 23 SEAL-O-RING | 5 | |
| 8T6762 | 24 PLUG-PIPE (1/2-14-THD) | 2 | |
| 9S8752 | 25 NUT-FULL (3/8-16-THD) | 6 | |
| 9X6458 | 26 WASHER-HARD (10.2X22.5X3-MM THK) | 4 |
