System And Components
377-9653 LINES GP-AFTERCOOLER AIRFIELD INSTALLATION
Group No: 377-9653
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W7111 | 1 FLANGE | 2 | |
| 4W3851 | 2 BRACKET | 2 | |
| 4W9725 | 3 GASKET | 2 | |
| 4W9726 | 4 FLANGE | 1 | |
| 7L4302 | 5 GASKET | 2 | |
| 1145275 | 6 ADAPTER | 1 | |
| 2086990 | 7 ELBOW (RH) | 1 | |
| 2086991 | 8 ELBOW (LH) | 1 | |
| 3982208 | 9 BRACKET | 1 | |
| 3982209 | 10 TUBE AS | 1 | |
| 0321268 | 11 CONNECTOR (90-DEG) | 1 | |
| 0S1585 | 12 BOLT (1/2-13X1.5-IN) | 6 | |
| 0S1588 | 13 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1594 | 14 BOLT (3/8-16X1-IN) | 1 | |
| 1A2029 | 15 BOLT (3/8-16X1.125-IN) | 2 | |
| 1A5822 | 16 BOLT (1/2-13X2.75-IN) | 6 | |
| 3535111 | 17 ADAPTER AS | 1 | |
| 7D9984 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 5M2894 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5P8245 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 5P8862 | 20 SEAL-O-RING | 2 | |
| 6V2695 | 21 SEAL-O-RING | 4 | |
| 6V3265 | 22 CLIP | 1 | |
| 6V3917 | 23 SEAL-O-RING | 4 | |
| 7B3235 | 24 BOLT (1/2-13X1.375-IN) | 6 | |
| 9S8752 | 25 NUT-FULL (3/8-16-THD) | 1 | |
| 9X6458 | 26 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 9X8874 | 27 BOLT (1/2-13X3-IN) | 2 |
