System And Components
423-3343 LINES GP-AIR (CHG -00 THRU -04)AIR INLET CHOKE
Group No: 423-3343
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I1705 | 1 WASHER | 1 | |
| 6I1706 | 2 COVER AS | 1 | |
| 6I1707 | 3 PLATE-STOP | 1 | |
| 6I1708 | 4 PLATE | 1 | |
| 0399234 | 5 ROD | 1 | |
| 1763583 | 6 GUARD | 2 | |
| 1763587 | 7 CLEVIS | 1 | |
| 1837232 | 8 BELLOWS AS | 1 | |
| 1937879 | 9 BOOT | 1 | |
| 2118175 | 10 ACTUATOR GP-ELECTRONIC (ELECTROHYDRAULIC) | 1 | |
| 2253769 | 11 ROD END | 1 | |
| 2279012 | 12 GASKET | 2 | |
| 4233344 | 13 ELBOW | 1 | |
| 4233345 | 14 BRACKET AS | 1 | |
| 4233346 | 15 SHAFT | 1 | |
| 4233350 | 16 BRACKET AS | 1 | |
| 4233352 | 17 HOUSING AS | 1 | |
| 5P0547 | SEAL-LIP TYPE | 1 | |
| 6V3365 | SEAL-LIP TYPE | 1 | |
| 1624217 | BUSHING | 2 | |
| 4260568 | 18 PLATE-BUTTERFLY | 1 | |
| 4314132 | 19 GASKET | 2 | |
| 0102575 | 20 SETSCREW (1/4-20X1-IN) | 1 | |
| 0310216 | 21 BOLT (1/4-20X0.75-IN) | 4 | |
| 1653931 | 22 BOLT (3/8-16X1.75-IN) | 2 | |
| 0S1585 | 23 BOLT (1/2-13X1.5-IN) | 8 | |
| 0S1589 | 24 BOLT (5/8-11X1.75-IN) | 5 | |
| 1C2251 | 25 BOLT (3/8-16X1.87-IN) | 1 | |
| 1653929 | 26 BOLT (3/8-16X1.5-IN) | 16 | |
| 0S1594 | 27 BOLT (3/8-16X1-IN) | 2 | |
| 1A2029 | 28 BOLT (3/8-16X1.125-IN) | 4 | |
| 1A9579 | 29 BOLT (5/16-18X1.5-IN) | 1 | |
| 1F7958 | 30 NUT-FULL (1/2-13-THD) | 1 | |
| 1S3584 | 31 NUT-FULL (3/8-24 LH-THD) | 1 | |
| 2253770 | 32 ROD END | 1 | |
| 2A4639 | 33 BOLT (3/8-16X1.625-IN) | 2 | |
| 2L0041 | 34 BOLT (1/2-13X2.25-IN) | 1 | |
| 3512247 | 35 BOLT (3/8-16X1.5-IN) | 4 | |
| 3S2713 | 36 NUT-FULL (3/8-24-THD) | 1 | |
| 3V3308 | 37 WASHER-HARD (10.2X20.5X2.5-MM THK) | 19 | |
| 4P0394 | 38 LEVER | 1 | |
| 5H2532 | 39 KEY-WOODRUFF | 1 | |
| 5M2894 | 40 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 5P8245 | 41 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 5P8247 | 42 WASHER-HARD (17X32X3.5-MM THK) | 5 | |
| 5S0003 | 43 NUT (5/16-18-THD) | 1 | |
| 7D1649 | 44 WASHER-HARD (13.5X32X5-MM THK) | 8 | |
| 8H3390 | 45 NUT-FULL (1-1/2-12-THD) | 1 | |
| 8M9024 | 46 WASHER-HARD (10.2X22.5X5-MM THK) | 1 | |
| 8S2332 | 47 BOLT-12 POINT HEAD (5/8-11X1.75-IN) | 6 | |
| 9S8752 | 48 NUT-FULL (3/8-16-THD) | 3 |
