System And Components
418-4693 BOX GP-CONTROL (CHG -00)OCP 4.3
Group No: 418-4693
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W3484 | 1 SPACER (9X18X30-MM THK) | 1 | |
| 3E1813 | 2 SWITCH AS-PUSH BUTTON (LIGHTED) | 1 | |
| 3E1814 | LAMP (24-VOLT) | 1 | |
| 1036272 | 3 SEAL | 1 | |
| 1152538 | 4 COVER-END | 2 | |
| 1165140 | 5 TERMINAL | 6 | |
| 1735413 | 6 CLAMP | 2 | |
| 2039007 | 7 NUT (1-1/2-18-THD) | 1 | |
| 2250547 | 8 BLOCK-TERMINAL | 81 | |
| 2250548 | 9 COVER | 3 | |
| 2250906 | 10 BRIDGE (2-POSITION) | 2 | |
| 2295291 | 11 TERMINAL | 5 | |
| 2702679 | 12 LOCKWASHER | 1 | |
| 2905562 | 13 MOUNT (DUAL SWIVEL) | 1 | |
| 3089773 | 14 SWITCH AS-PUSH BUTTON (RED) | 1 | |
| 3089774 | 15 RING | 1 | |
| 3089775 | 16 LATCH-MOUNTING | 1 | |
| 3089777 | 17 BLOCK-CONTACT | 2 | |
| 3149101 | 18 BRACKET-END | 4 | |
| 3392958 | 19 GASKET | 1 | |
| 3407298 | 20 CAP AS-PROTECTION | 1 | |
| 3503459 | 21 MODULE | 1 | |
| 3687965 | 22 CONTROL GP-GENERATOR SET | 1 | |
| 3862036 | 23 HARNESS AS-PANEL (BOX) | 1 | |
| 3862037 | 24 HARNESS AS-WIRING (INTERCONNECT) | 1 | |
| 4184666 | 25 BOX AS-CONTROL | 1 | |
| 5P5921 | SEAL (3-M) | ||
| 6V1392 | SEAL (1.7-M) | ||
| 7T1099 | LINK | 12 | |
| 1533723 | HINGE AS | 2 | |
| 8T5447 | RING-RETAINING | 1 | |
| 3393085 | LATCH AS | 2 | |
| 4336753 | 26 MARKER AS-TERMINAL | 1 | |
| 4336762 | 27 BLOCK-TERMINAL | 2 | |
| 4336764 | 28 PLUG | 2 | |
| 0L1143 | 30 BOLT (3/8-16X2.5-IN) | 1 | |
| 1391398 | 31 CLIP (LOOP) | 2 | |
| 1F5842 | 32 BOLT (5/16-18X3.25-IN) | 1 | |
| 3023908 | 33 SPACER (11X20X30-MM THK) | 1 | |
| 3E4352 | 34 WASHER-HARD (8.8X20.5X2.5-MM THK) | 2 | |
| 5M2894 | 35 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5S0003 | 36 NUT (5/16-18-THD) | 1 | |
| 6V8225 | 37 NUT (M6X1-THD) | 6 | |
| 7K1181 | 38 STRAP-CABLE | 11 | |
| 9X8267 | 39 WASHER (6.6X12X2-MM THK) | 6 | |
| 1H3338 | 40 LOCKWASHER | 6 |
