System And Components
418-4693 BOX GP-CONTROL (CHG -01, -02)OCP 4.3
Group No: 418-4693
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 9 | |
| 1036272 | 2 SEAL | 1 | |
| 1152538 | 3 COVER-END | 2 | |
| 1165140 | 4 TERMINAL | 6 | |
| 1735413 | 5 CLAMP | 6 | |
| 2039007 | 6 NUT (1-1/2-18-THD) | 1 | |
| 2250547 | 7 BLOCK-TERMINAL | 81 | |
| 2250548 | 8 COVER | 3 | |
| 2250906 | 9 BRIDGE (2-POSITION) | 2 | |
| 2295291 | 10 TERMINAL | 5 | |
| 2702679 | 11 LOCKWASHER | 1 | |
| 3392958 | 12 GASKET | 1 | |
| 3407298 | 13 CAP AS-PROTECTION | 1 | |
| 3503459 | 14 MODULE | 1 | |
| 3687965 | 15 CONTROL GP-GENERATOR SET | 1 | |
| 3862036 | 16 HARNESS AS-PANEL | 1 | |
| 3901208 | 17 SHROUD | 1 | |
| 3901209 | 18 SWITCH AS (EMERGENCY STOP) | 1 | |
| 4184666 | 19 BOX AS-CONTROL | 1 | |
| 4200437 | 20 SWITCH-PUSH | 1 | |
| 4336753 | 21 MARKER AS-TERMINAL | 1 | |
| 4336762 | 22 BLOCK-TERMINAL | 2 | |
| 4336764 | 23 PLUG | 2 | |
| 4484866 | 24 GASKET | 1 | |
| 4606273 | 25 FILM-IDENTIFICATION (CONTROL PANEL) | 1 | |
| 1H3338 | 26 LOCKWASHER | 6 | |
| 6V8225 | 27 NUT (M6X1-THD) | 6 | |
| 9X8267 | 28 WASHER (6.6X12X2-MM THK) | 6 |
