System And Components
418-4686 CONTROL GP-ENGINE ELECTRONIC (CHG -06, -07)
Group No: 418-4686
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W6090 | 1 PLATE-IDENTIFICATION (EMERGENCY STOP) | 1 | |
| 3S2093 | 2 STRAP-CABLE | 11 | |
| 4B8407 | 3 GASKET-COPPER | 1 | |
| 8T9655 | 4 MOUNT-ISOLATION | 16 | |
| 1735413 | 5 CLAMP | 2 | |
| 1057542 | 6 STRIP-CONTACT | 1 | |
| 1057543 | 7 BLOCK-FUSE | 6 | |
| 1833192 | 8 SEAL AS (CONDUIT HOLE) | 1 | |
| 2045593 | 9 RELAY (24-VOLT)(FUEL) | 1 | |
| 2045593 | 9A RELAY (24-VOLT)(COMPRESSOR BYPASS) | 1 | |
| 2345925 | GASKET | 1 | |
| 2345925 | 10 GASKET | 1 | |
| 2829115 | 11 CAP AS-CONNECTOR | 2 | |
| 3089773 | 12 SWITCH AS-PUSH BUTTON (RED)(EMERGENCY STOP) | 1 | |
| 3089774 | 13 RING | 1 | |
| 3089775 | 14 LATCH-MOUNTING | 1 | |
| 3089777 | 15 BLOCK-CONTACT | 2 | |
| 3203063 | 16 SENSOR GP-PRESSURE (ATMOSPHERIC) | 1 | |
| 3238737 | 17 CONTROL GP-UNPROGRAMMED (ELECTRONIC)(ECM) | 1 | |
| 3392958 | 18 GASKET | 1 | |
| 3407298 | 19 CAP AS-PROTECTION | 1 | |
| 3538088 | 20 CONTROL GP-UNPROGRAMMED (ISM) | 1 | |
| 3862014 | 21 RAIL AS | 1 | |
| 3862055 | 22 GASKET | 2 | |
| 4184689 | 23 ADAPTER AS | 1 | |
| 4184690 | 24 WIRING GP-ENGINE | 1 | |
| 4321818 | 25 BRACKET | 2 | |
| 4443370 | 26 ADAPTER AS | 1 | |
| 4563745 | 27 SUPPORT | 2 | |
| 5136238 | 28 BLOCK-TERMINAL | 7 | |
| 5170939 | 29 COVER-END | 2 | |
| 5192862 | 30 STRIP-CONTACT | 1 | |
| 5360125 | 31 STRIP-CONTACT | 1 | |
| 0365774 | 32 FUSE (15-AMPERE) | 3 | |
| 0S1615 | 33 BOLT (1/4-20X0.75-IN) | 1 | |
| 0S1616 | 34 BOLT (1/4-20X1-IN) | 1 | |
| 0T0102 | 35 BOLT (3/8-16X0.625-IN) | 4 | |
| 1B9575 | 36 BOLT (5/16-18X1.56-IN) | 4 | |
| 2039007 | 37 NUT (1-1/2-18-THD) | 1 | |
| 2147568 | 38 SEAL-O-RING | 1 | |
| 2574907 | 39 COVER AS-ACCESS | 1 | |
| 2702679 | 40 LOCKWASHER | 1 | |
| 2B2694 | 41 BOLT (5/16-18X2-IN) | 2 | |
| 2P1279 | 42 LOCKNUT (9/16-18-THD) | 1 | |
| 3353999 | 43 CONNECTOR | 1 | |
| 3J1907 | 44 SEAL-O-RING | 2 | |
| 4563742 | 45 BOX GP-JUNCTION | 1 | |
| 4L7547 | 46 STUD-TAPERLOCK (5/16-18X2-IN) | 2 | |
| 4P7581 | 47 CLIP (LADDER) | 1 | |
| 4P8134 | 48 CLIP (LADDER) | 5 | |
| 5360101 | 49 MARKER-TERMINAL | 1 | |
| 5M2894 | 50 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5P0537 | 51 WASHER-HARD (7.2X14.5X2-MM THK) | 13 | |
| 5P4115 | 52 WASHER-HARD (7.2X19X2-MM THK) | 3 | |
| 6I1418 | 53 SPACER (8.2X12.7X28.7-MM THK) | 8 | |
| 6V5683 | 54 BOLT (M6X1X16-MM) | 4 | |
| 6V8076 | 55 ELBOW | 1 | |
| 6V9028 | 56 SEAL-O-RING | 1 | |
| 7X7945 | 57 ADAPTER (9/16-18-THD) | 1 | |
| 9M1974 | 58 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9N0869 | 59 WASHER-HARD (8.8X25.5X2-MM THK) | 12 | |
| 9S8750 | 60 NUT-FULL (1/4-20-THD) | 14 | |
| 9S8752 | 61 NUT-FULL (3/8-16-THD) | 2 | |
| 9Y6027 | 62 FUSE-CERAMIC (10-AMPERE) | 3 |
