System And Components
418-4667 WIRING GP-SENSOR (CHG -00)
Group No: 418-4667
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1160118 | 1 CLIP | 1 | |
| 6V3260 | 2 BOLT-SOCKET HEAD (1/4-20X0.75-IN) | 2 | |
| 3579026 | 3 CLAMP | 4 | |
| 3579030 | 4 CLAMP | 2 | |
| 3579031 | 5 CLAMP | 2 | |
| 3579032 | 6 CLAMP | 12 | |
| 3579033 | 7 CLAMP | 11 | |
| 3596001 | 8 BRACKET AS | 1 | |
| 3596007 | 9 BRACKET AS | 1 | |
| 3596010 | 10 BRACKET AS | 1 | |
| 3596013 | 11 BRACKET AS | 9 | |
| 3596015 | 12 BRACKET AS | 1 | |
| 3609581 | 13 BRACKET AS | 1 | |
| 3722933 | 14 BRACKET AS | 4 | |
| 3722938 | 15 BRACKET AS | 1 | |
| 3724756 | 16 BRACKET | 1 | |
| 3724757 | 17 BRACKET AS | 9 | |
| 3774634 | 18 BRACKET AS | 1 | |
| 3774638 | 19 BRACKET | 2 | |
| 3774639 | 20 BRACKET AS | 2 | |
| 3774640 | 21 BRACKET AS | 1 | |
| 3862023 | 22 BRACKET AS | 1 | |
| 4184668 | 23 HARNESS GP-WIRING (RAIL) | 1 | |
| 4184677 | 24 HARNESS AS-ENGINE (SENSORS) | 1 | |
| 4184678 | 25 HARNESS AS-SENSOR (RH) | 1 | |
| 4184679 | 26 HARNESS AS-ENGINE (COMPRESSOR BYPASS) | 1 | |
| 4184680 | 27 HARNESS AS-SENSOR (AIR SYSTEM) | 1 | |
| 4184681 | 28 BRACKET AS | 1 | |
| 4184682 | 29 HARNESS AS-SENSOR (NOX REDUCTION SYSTEM) | 1 | |
| 4184683 | 30 BRACKET AS | 1 | |
| 4319490 | 31 BRACKET AS | 2 | |
| 4320126 | 32 BRACKET | 2 | |
| 4321818 | 33 BRACKET | 2 | |
| 0L1351 | 34 BOLT (3/8-16X0.875-IN) | 7 | |
| 0L2070 | 35 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S0509 | 36 BOLT (3/8-16X0.75-IN) | 3 | |
| 1653931 | 37 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1587 | 38 BOLT (1/2-13X1.75-IN) | 2 | |
| 0S1588 | 39 BOLT (3/8-16X1.25-IN) | 4 | |
| 0S1591 | 40 BOLT (3/8-16X1.5-IN) | 6 | |
| 0S1594 | 41 BOLT (3/8-16X1-IN) | 2 | |
| 0S1618 | 42 BOLT (5/16-18X1-IN) | 2 | |
| 0S1626 | 43 BOLT (3/4-10X1.5-IN) | 1 | |
| 1325789 | 44 CLIP (LADDER) | 1 | |
| 9X8256 | 45 WASHER (6.6X12X2-MM THK) | 2 | |
| 1A2029 | 46 BOLT (3/8-16X1.125-IN) | 2 | |
| 1C2251 | 47 BOLT (3/8-16X1.87-IN) | 2 | |
| 2A4639 | 48 BOLT (3/8-16X1.625-IN) | 2 | |
| 2H0191 | 49 BOLT (10-24X0.625-IN) | 23 | |
| 2N0402 | 50 BOLT-SOCKET HEAD (10-24X1.75-IN) | 8 | |
| 3094314 | 51 CLIP (LADDER) | 1 | |
| 3B1915 | 52 BOLT (3/8-16X1.375-IN) | 9 | |
| 3E4352 | 53 WASHER-HARD (8.8X20.5X2.5-MM THK) | 2 | |
| 3V3308 | 54 WASHER-HARD (10.2X20.5X2.5-MM THK) | 41 | |
| 4P7428 | 55 CLIP (LADDER) | 1 | |
| 4P7429 | 56 CLIP (LADDER) | 2 | |
| 4P7581 | 57 CLIP (LADDER) | 1 | |
| 5J1714 | 58 BOLT (10-24X1.5-IN) | 8 | |
| 5L9018 | 59 BOLT-SOCKET HEAD (1/4-20X1.75-IN) | 10 | |
| 5P0537 | 60 WASHER-HARD (7.2X14.5X2-MM THK) | 10 | |
| 5P8245 | 61 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 5P8248 | 62 WASHER-HARD (20X36.5X3.5-MM THK) | 1 | |
| 6V1581 | 63 CLIP (SLOT) | 1 | |
| 6V1582 | 64 CLIP (TAB) | 1 | |
| 6V2317 | 65 BOLT (M8X1.25X30-MM) | 1 | |
| 6V3940 | 66 BOLT (M8X1.25X25-MM) | 1 | |
| 6V7697 | 67 SCREW-MACHINE (8-32X1.25-IN) | 8 | |
| 7D1649 | 68 WASHER-HARD (13.5X32X5-MM THK) | 2 | |
| 7K1181 | 69 STRAP-CABLE | 6 | |
| 7L0688 | 70 BOLT-SOCKET HEAD (10-24X1.2-IN) | 6 | |
| 7X3364 | 71 BOLT (10-24X1.25-IN) | 2 | |
| 7X7908 | 72 CLIP | 2 | |
| 8H3128 | 74 BOLT-SOCKET HEAD (1/4-20X0.625-IN) | 6 | |
| 8T0328 | 75 WASHER-HARD (5.5X10X1-MM THK) | 24 | |
| 9M1974 | 76 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9S8752 | 77 NUT-FULL (3/8-16-THD) | 8 | |
| 9X2646 | 78 CLIP (SLOT) | 2 | |
| 9X2647 | 79 CLIP (TAB) | 2 | |
| 9X6458 | 80 WASHER-HARD (10.2X22.5X3-MM THK) | 5 | |
| 2B0947 | 81 BOLT (1/2-13X2.25-IN) | 1 |
