System And Components
423-9011 LINES GP-HYDRAULIC (CHG -00 THRU -02)HYDRAC DISCHARGE
Group No: 423-9011
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8C0569 | 1 TEE-O-RING | 2 | |
| 8C5053 | 2 ADAPTER | 1 | |
| 1216750 | 3 MANIFOLD | 2 | |
| 1386144 | 4 FILTER GP-ENGINE OIL | 1 | |
| 1386158 | 5 VALVE-CHECK | 1 | |
| 1763586 | 6 VALVE AS-RELIEF (ENGINE OIL) | 1 | |
| 2M9780 | SEAL-O-RING | 2 | |
| 5E4852 | VALVE-RELIEF (ENGINE OIL) | 1 | |
| 4233357 | 7 BRACKET AS | 1 | |
| 4233358 | 8 BRACKET | 1 | |
| 4233359 | 9 BRACKET | 1 | |
| 4239014 | 10 TUBE AS | 1 | |
| 4239016 | 11 TUBE AS | 1 | |
| 4239017 | 12 TUBE AS | 1 | |
| 4239018 | 13 TUBE AS | 1 | |
| 4239019 | 14 TUBE AS | 1 | |
| 4260566 | 15 BRACKET | 1 | |
| 4378356 | 16 TUBE AS | 1 | |
| 4378357 | 17 TUBE AS | 1 | |
| 4378358 | 18 TUBE AS | 1 | |
| 4394490 | 19 BRACKET | 1 | |
| 4438073 | 20 TUBE AS | 1 | |
| 0S1588 | 21 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1590 | 22 BOLT (3/8-16X2-IN) | 2 | |
| 1653929 | 23 BOLT (3/8-16X1.5-IN) | 4 | |
| 0S1594 | 24 BOLT (3/8-16X1-IN) | 13 | |
| 0T0065 | 25 BOLT (3/8-16X3.5-IN) | 2 | |
| 1A2029 | 26 BOLT (3/8-16X1.125-IN) | 9 | |
| 2M9780 | 27 SEAL-O-RING | 7 | |
| 3023908 | 28 SPACER (11X20X30-MM THK) | 2 | |
| 3139198 | 29 CLIP | 1 | |
| 3D2824 | 30 SEAL-O-RING | 8 | |
| 3J1907 | 31 SEAL-O-RING | 7 | |
| 3K0360 | 32 SEAL-O-RING | 2 | |
| 3S8664 | 33 CLIP | 7 | |
| 3V3308 | 34 WASHER-HARD (10.2X20.5X2.5-MM THK) | 34 | |
| 5P9299 | 35 CLIP (LOOP) | 6 | |
| 6V8398 | 36 SEAL-O-RING | 8 | |
| 6V8637 | 37 CONNECTOR | 2 | |
| 6V8639 | 38 CONNECTOR | 1 | |
| 6V8640 | 39 CONNECTOR | 1 | |
| 6V8721 | 40 ELBOW | 3 | |
| 6V8784 | 41 TEE-FACE SEAL | 1 | |
| 6V9007 | 42 ELBOW | 2 | |
| 6V9182 | 43 ELBOW | 1 | |
| 6V9746 | 44 SEAL-O-RING | 12 | |
| 6V9832 | 45 CAP (ORFS) | 1 | |
| 6V9877 | 46 ELBOW | 1 | |
| 7C9560 | 47 SPACER (10.5X25X51-MM THK) | 2 | |
| 7I8310 | 48 CONNECTOR | 1 | |
| 7M8485 | 49 SEAL-O-RING | 1 | |
| 8T5389 | 50 ELBOW | 1 | |
| 8T6876 | 51 ELBOW | 4 | |
| 9S4190 | 52 PLUG-O-RING (7/8-14-THD) | 2 | |
| 9S4191 | 53 PLUG (9/16-18-THD) | 3 | |
| 9S8752 | 54 NUT-FULL (3/8-16-THD) | 9 | |
| 9X6458 | 55 WASHER-HARD (10.2X22.5X3-MM THK) | 6 |
